1SCA140084R1001 ABB OTDC160E12 3 Pole 1000VDC 160A Switch Disconnector
MPN: 1SCA140084R1001
Alt. SKU: OTDC160E12
Why Choose the OTDC160E12 [1SCA140084R1001]
The OTDC160E12 is a DC switch-disconnector rated for 160 A at 1000 VDC, designed for base mounting applications. It includes a terminal bolt kit for secure connections. Please note that the handle and shaft must be ordered separately to complete the assembly. This switch-disconnector complies with IEC standards, ensuring reliable isolation in DC electrical systems.
Technical Specification
- Function: DC switch-disconnector.
- Rated Operational Voltage: 1000 V DC.
- Rated Operational Current: 160 A (DC-21B).
- Contact Configuration: 3 poles (3P), single circuit.
- Rated Insulation Voltage (Ui): 1500 V.
- Rated Impulse Withstand Voltage (Uimp): 12 kV.
- Degree of Protection: Front IP20.
- Terminal Type and Size: Lug terminals, 19.5 mm width.
- Mounting Type: Base mounting.
- Mechanical Data: Shaft diameter 6 mm; Positive opening torque 5–8 N·m.
Trusted By Customers Worldwide
"Specified by UK panel builders for dependable control." Controls Engineer, UK
Frequently Asked Questions
What is the rated operational voltage of the OTDC160E12?
The rated operational voltage is 1000 V DC.
What is the rated operational current for this switch-disconnector?
The rated operational current is 160 A (DC-21B).
What is the contact configuration of the OTDC160E12?
The contact configuration is 3 poles (3P), single circuit.
What type of terminals does the OTDC160E12 use?
It uses lug terminals with a width of 19.5 mm.
How is the OTDC160E12 mounted?
The switch-disconnector is designed for base mounting.
What is the degree of protection for the OTDC160E12?
The degree of protection is IP20 for the front.
What standards and approvals does the OTDC160E12 comply with?
See the manufacturer's data sheet for standards and approvals.
| Alternative Product SKU | OTDC160E12 |
|---|---|
| Manufacturer Part Number | 1SCA140084R1001 |
| Manufacturer | ABB |
| Barcode | 6417019679044 |
| Number of Poles | 3 Pole |
| Number of switches | 1 |
| Rated operating voltage | 1000 |
| Device construction | Built-in device fixed built-in technique |
| Type of control element | Other |
| Rated permanent current Iu | 160A |
| Voltage | 1000VDC |
| Degree of protection (IP) | IP20 |
| Nema Rating | 1 |
| Type of electric connection | Bolt connection |
| Packed Quantity | 1 |
| Height | 176mm |
| Width | 151mm |
| Depth | 74mm |
| HS Code | 85365080 |
| Country of Manufacture | Finland |
