ABB jshd2c type k Enabling Switch
MPN: 2TLA020001R1300
Alt. SKU: JSHD2C type K
Special Price
£55.45
£46.21
Regular Price
£65.23
Why Choose the JSHD2C type K [2TLA020001R1300]
The JSHD2C Type K is a three-position pushbutton with silver plated contacts and 2 leads, each 290 mm. The force needed to actuate the push-button from middle to bottom is 20 N. Three-position pushbuttons are usually used in pair in a three-position device.
Technical Specification
- Function: Three-position pushbutton with silver plated contacts.
- Rated Operational Current: 24 V DC, 0.02 A.
- Contact Configuration: 1 Normally Closed (NC) and 1 Normally Open (NO).
- Connection Type: 2 leads, 290 mm each.
- Actuation Force: 20 N from middle to bottom position.
- Mechanical Life: Over 1 million cycles (top to middle), over 100,000 cycles (middle to bottom).
- Weight: 0.01 kg.
Trusted By Customers Worldwide
"Specified by UK panel builders for dependable control." Controls Engineer, UK
Frequently Asked Questions
What is the function of the JSHD2C Type K pushbutton?
The JSHD2C Type K is a three-position pushbutton designed for control applications, featuring silver plated contacts.
What is the rated operational current for this pushbutton?
The rated operational current is 24 V DC at 0.02 A.
What is the actuation force required for the pushbutton?
The actuation force needed to move the pushbutton from the middle to the bottom position is 20 N.
How is the JSHD2C Type K pushbutton connected?
It features a connection type of 2 leads, each measuring 290 mm.
What is the mechanical life of the pushbutton?
The mechanical life is over 1 million cycles from top to middle and over 100,000 cycles from middle to bottom.
Is the JSHD2C Type K pushbutton compliant with any standards?
See the manufacturer's data sheet for standards and approvals.
| Manufacturer | ABB |
|---|---|
| HS Code | 85365080 |
| Barcode | 7350024456851 |
| Country of Manufacture | Sweden |
| Alternative Product SKU | JSHD2C type K |
| Manufacturer Part Number | 2TLA020001R1300 |
