SDR-480P-48 Power Supply 90-264VAC 1 phase input, output 48 volts DC 10.0 Amps
MPN: SDR-480P-48
Alt. SKU: SDR480P48
£237.60
£198.00
Why Choose the Mean Well SDR-480P-48 DIN Rail Power Supply?
The Mean Well SDR-480P-48 is a premium, programmable 480W DIN rail power supply built for advanced industrial, automation, and machinery applications. Offering a stable 48V DC output at 10A, it features a programmable output voltage range, built-in parallel operation, active power factor correction, comprehensive protection mechanisms, and DC OK relay contact—delivering robust and intelligent power for mission-critical systems.
Key Takeaways
- Output: 48V DC at 10A (480W)
- Programmable output voltage: 41–56V via external signal
- Input Voltage: 88–264V AC / 124–370V DC
- High efficiency up to 94%
- Built-in active power factor correction (PFC)
- Built-in parallel function (up to 2 units)
- Protections: Short circuit, overload, over voltage, over temperature
- DC OK relay contact for remote monitoring
- Cooling by free air convection
- DIN rail mountable (TS35/7.5 or TS35/15)
- Metal case: 85.5mm width
- Operating temperature: -25°C to +70°C
- Compliance: UL508, EN61000-6-2, EN61000-6-4, TUV EN62368-1, CE
Frequently Asked Questions About the Mean Well SDR-480P-48
- What is the output voltage and current of the SDR-480P-48?
- What programming features are available?
- Does this model support parallel operation?
- What protection features are included?
- Is remote DC OK monitoring supported?
Mean Well SDR-480P-48 Overview
The SDR-480P-48 belongs to Mean Well’s advanced SDR series, featuring programmable output, built-in parallel function, and DC OK relay contact for remote monitoring. With a steady 48V DC at 10A and output voltage programmable between 41V and 56V, this model is ideal for sophisticated automation and power-hungry industrial systems that demand flexible and reliable energy supply.
Speed & Safety Benefits
- Quick installation: DIN rail mounting saves space and simplifies wiring
- Enhanced safety: Comprehensive protections safeguard equipment and personnel
- Efficient & scalable: Programmable output and parallel operation enable flexible, redundant power solutions
Key Features of the Mean Well SDR-480P-48
- Output: 48V DC at 10A (480W)
- Programmable output voltage: 41–56V (via external signal)
- Input Voltage: 88–264V AC / 124–370V DC
- High efficiency up to 94%
- Active power factor correction (PFC)
- Parallel operation function (up to 2 units)
- Protections: Short circuit, overload, over voltage, over temperature
- DC OK relay contact for remote monitoring
- Cooling by free air convection
- DIN rail mountable (TS35/7.5 or TS35/15)
- Metal case: 85.5mm width
- Operating temperature: -25°C to +70°C
- Compliance: UL508, EN61000-6-2, EN61000-6-4, TUV EN62368-1, CE
The SDR-480P-48 provides a 48V DC output at 10A, for a total power of 480W. The output voltage can be programmed from 41V to 56V via an external control signal.
The output voltage is programmable between 41V and 56V using an external control signal, allowing for customized voltage levels to match specific application requirements.
Yes, the SDR-480P-48 includes built-in parallel function, enabling up to 2 units to be connected for increased current or system redundancy.
This power supply features comprehensive protection, including short circuit, overload, over voltage, and over temperature safeguards.
Yes, the SDR-480P-48 has a DC OK relay contact for remote output monitoring and easy integration into supervisory control systems.
Choose the Mean Well SDR-480P-48 DIN Rail Power Supply for programmable, scalable, and reliable power delivery in advanced automation and industrial environments.
| Manufacturer Part Number | SDR-480P-48 |
|---|---|
| Barcode | 4711287422435 |
| Manufacturer | Meanwell |
| Output Voltage | 48VDC |
| Product Lead Time | In Stock 2/3 days Delivery |
| Output Current | 10A |
| Input Phases | Single Phase |
| Alternative Product SKU | SDR480P48 |
