S204M-C63 Miniature Circuit Breaker - 4P - C - 63 A
MPN: 2CDS274001R0634
Alt. SKU: S204MC63
Special Price
£134.54
£112.12
Regular Price
£244.62
Why Choose the S204M-C63 [2CDS274001R0634]
System pro M compact S200M miniature circuit breakers are current limiting. They have two different tripping mechanisms, the delayed thermal tripping mechanism for overload protection and the electromechanic tripping mechanism for short circuit protection. They are available in different characteristics (B,C,D,K,Z), configurations (1P,1P+N,2P,3P,3P+N,4P), breaking capacities (up to 10 kA at 230/400 V AC) and rated currents (up to 63A). All MCBs of the product range S200M comply with IEC/EN 60898-1 and IEC/EN 609 47-2, allowing the use for residential, commercial and industrial applications. Bottom-fitting auxiliary contact can be mounted on S200M to save 50% space.
Technical Specification
- Function: Current limiting miniature circuit breaker with thermal and electromechanical tripping for overload and short circuit protection.
- Rated Current: Up to 63A.
- Voltage Ratings: 230/400 V AC.
- Contact Configuration: 4 poles (4P).
- Breaking Capacity: Ultimate up to 25 kA at 230 V AC, 15 kA at 400/440 V AC.
- Terminal Type and Capacity: Screw terminals; 0.75 to 35 mm² flexible and rigid cables, busbar 10/10 mm².
- Electrical Endurance: 10,000 AC cycles.
- Mechanical Endurance: 20,000 cycles.
- Dielectric Test Voltage: 2 kV at 50/60 Hz for 1 minute.
- Actuator: Toggle type with red ON/green OFF indication, sealable black insulation.
Trusted By Customers Worldwide
"Specified by UK panel builders for dependable control." Controls Engineer, UK
Frequently Asked Questions
What is the maximum rated current for the S200M miniature circuit breakers?
The maximum rated current for the S200M miniature circuit breakers is up to 63A.
What are the available breaking capacities for the S200M?
The breaking capacities are up to 25 kA at 230 V AC and 15 kA at 400/440 V AC.
Can the S200M be used in residential applications?
Yes, the S200M complies with IEC/EN 60898-1, making it suitable for residential, commercial, and industrial applications.
What types of cables can be connected to the S200M terminals?
The S200M has screw terminals that can accommodate flexible and rigid cables from 0.75 to 35 mm², and busbars of 10/10 mm².
What tripping mechanisms are used in the S200M?
The S200M uses a delayed thermal tripping mechanism for overload protection and an electromechanical tripping mechanism for short circuit protection.
Is it possible to mount auxiliary contacts on the S200M?
Yes, a bottom-fitting auxiliary contact can be mounted on the S200M to save 50% space.
What standards does the S200M comply with?
See the manufacturer's data sheet for standards and approvals.
| Manufacturer Part Number | 2CDS274001R0634 |
|---|---|
| Packed Quantity | 1 |
| Barcode | 4016779544047 |
| HS Code | 85362010 |
| Country of Manufacture | Germany |
| Manufacturer | ABB |
| Number of Poles | 4 Pole |
| Amperage | 63A |
| Alternative Product SKU | S204MC63 |
