S202-B2 Miniature Circuit Breaker - 2P - B - 2 A
MPN: 2CDS252001R0025
Alt. SKU: S202-B2
Special Price
£44.86
£37.38
Regular Price
£81.55
Why Choose the S202-B2 [2CDS252001R0025]
System pro M compact S200 miniature circuit breakers are current limiting. They have two different tripping mechanisms, the delayed thermal tripping mechanism for overload protection and the electromechanic tripping mechanism for short circuit protection. They are available in different characteristics (B,C,D,K,Z), configurations (1P,1P+N,2P,3P,3P+N,4P), breaking capacities (up to 6 kA at 230/400 V AC) and rated currents (up to 63A). All MCBs of the product range S200 comply with IEC/EN 60898-1, IEC/EN 60947-2, UL1077 allowing the use for residential, commercial and industrial applications. Bottom-fitting auxiliary contact can be mounted on S200 to save 50% space.
Technical Specification
- Function: Miniature circuit breaker with thermal overload and electromechanical short circuit protection.
- Rated Current: Up to 63A.
- Voltage Ratings: 125 V DC, 230/400/440 V AC.
- Contact Configuration: 2 poles (2P).
- Breaking Capacity: Up to 20 kA (230 V AC), 10 kA (400 V AC), 10 kA (125 V DC).
- Terminal Type: Screw terminals, bi-directional cylinder-lift.
- Connecting Capacity: Flexible cables up to 25 mm², rigid cables up to 35 mm².
- Mechanical Endurance: 20,000 operating cycles.
- Electrical Endurance: 20,000 AC cycles.
- Contact Position Indication: Red ON / Green OFF.
Trusted By Customers Worldwide
"Specified by UK panel builders for dependable control." Controls Engineer, UK
Frequently Asked Questions
What is the maximum rated current for the S200 miniature circuit breakers?
The maximum rated current for the S200 miniature circuit breakers is up to 63A.
What types of tripping mechanisms are used in the S200 MCBs?
The S200 MCBs utilise a delayed thermal tripping mechanism for overload protection and an electromechanical tripping mechanism for short circuit protection.
What is the breaking capacity of the S200 circuit breakers?
The breaking capacity is up to 20 kA at 230 V AC, 10 kA at 400 V AC, and 10 kA at 125 V DC.
What cable sizes can be connected to the S200 MCBs?
Flexible cables up to 25 mm² and rigid cables up to 35 mm² can be connected to the S200 MCBs.
Are the S200 miniature circuit breakers suitable for industrial applications?
Yes, the S200 MCBs comply with IEC/EN 60898-1, IEC/EN 60947-2, and UL1077, making them suitable for residential, commercial, and industrial applications.
Can auxiliary contacts be mounted on the S200 MCBs?
Yes, bottom-fitting auxiliary contacts can be mounted on the S200 to save 50% space.
What is the mechanical endurance of the S200 circuit breakers?
The mechanical endurance of the S200 circuit breakers is rated for 20,000 operating cycles.
| Manufacturer Part Number | 2CDS252001R0025 |
|---|---|
| Packed Quantity | 5 |
| Barcode | 4016779612920 |
| Manufacturer | ABB |
| Number of Poles | 2 Pole |
| Amperage | 2A |
| Alternative Product SKU | S202-B2 |
