RGTS24160FV00 - 1-PHASE SOFT STARTER 16A

Why Choose the Carlo Gavazzi RGTS24160FV00 Soft Starter?

The Carlo Gavazzi RGTS24160FV00 is a compact and dependable single-phase soft starter designed for induction motors in industrial and commercial motor control applications. As part of the advanced Carlo Gavazzi RGTS series, it delivers smooth motor acceleration while helping reduce electrical inrush current, mechanical stress and wear on motors and connected drive systems.

This soft starter uses solid-state switching technology to provide controlled motor startup performance while improving operational reliability and helping extend equipment service life. The RGTS series is designed for straightforward installation and supports both DIN rail and panel mounting, making it ideal for industrial automation panels and HVAC systems.

With a rated operational current of 16 A, an operating voltage range of 100–240 V AC, and a 24 V AC/DC supply input, the RGTS24160FV00 is suitable for compressors, pumps, fans and general-purpose induction motor applications requiring reliable soft starting functionality.

Key Advantages

• Compact single-phase soft starter for induction motors.
• 16 A operational current rating suitable for industrial motor applications.
• Reduces motor inrush current and mechanical stress during startup.
• Solid-state switching technology for dependable operation.
• 24 V AC/DC supply input simplifies automation integration.
• Supports both DIN rail and panel mounting.

Key Features

• Carlo Gavazzi RGTS soft starter series.
• Single-phase induction motor soft starter.
• 16 A rated operational current.
• 100–240 V AC operating voltage.
• 24 V AC/DC supply voltage.
• Solid-state motor starting functionality.
• DIN rail and panel mounting compatibility.
• Compact industrial enclosure design.

Technical Specifications

• Manufacturer: Carlo Gavazzi
• Series: RGTS Soft Starters
• Model: RGTS24160FV00
• Product type: Single-phase soft starter
• Rated operational current: 16 A
• Rated operating voltage: 90–264 V AC
• Supply voltage: 24 V AC/DC
• Motor power rating: approx. 1.5 kW at 230 V
• Frequency: 50 / 60 Hz
• Motor type: Single-phase induction motor
• Internal bypass: No
• Mounting type: DIN rail / panel mount
• Protection rating: IP20
• Operating temperature: -40°C to +60°C
• Product width: 54 mm
• Product height: 110 mm
• Product depth: 113 mm
• Electrical connection: Terminal block
• Standards: IEC industrial motor control standards

Reliable Soft Starting for Industrial Motor Applications

Soft starters such as the Carlo Gavazzi RGTS24160FV00 gradually ramp motor voltage during startup, helping reduce electrical peak current and minimising mechanical shock to motors and connected drive systems. This controlled startup process improves operational reliability while helping extend motor service life.

The RGTS range is trusted by industrial engineers and automation professionals because of its compact design, dependable solid-state switching technology and flexible mounting options. Its 24 V AC/DC supply input also enables straightforward integration into industrial automation systems and HVAC control panels.

Typical Applications

• Single-phase induction motor systems.
• HVAC compressors and ventilation systems.
• Industrial pumps and water systems.
• Fans and blower applications.
• Commercial motor control systems.
• Industrial automation and control panels.

Trusted by Industrial Automation Professionals Worldwide

Carlo Gavazzi RGTS soft starters are trusted by industrial engineers and panel builders for reliable motor starting, compact installation and dependable industrial performance.
