RFN380250 - T/O RELAY 1 6-2 5A MAN/AUTO

Why Choose the RFN380250?

Lovato RFN380250 thermal overload relay safeguards three‑phase motors within the 1.6…2.5 A operating range. It mounts directly on BF09…BF38 contactors and supports manual or automatic resetting in a three‑pole design. This type is non phase failure / non single‑phase sensitive, offering reliable motor protection for BF series control gear in demanding industrial environments.

Built for compliance and longevity, the relay provides Ui 690 V and 6 kV impulse withstand, with IP20 frontal protection and pollution degree 3. Rated Ith 10 A, it operates from −25 to 60 °C and up to 3000 m altitude. Terminal tightening torque is 2 to 2.5 Nm. Conforms to IEC/EN 60947‑1 and 60947‑4‑1, UL508 and CSA C22.2 n° 14.

Key Benefits

• Three‑pole design protects three‑phase motors reliably and efficiently.
• Operating range 1.6…2.5 A for correctly matched motor protection.
• Manual or automatic reset options to suit application and maintenance needs.
• Direct mounting on BF09…BF38 contactors for fast, tidy installation.
• Rated Ui 690 V and Uimp 6 kV for robust insulation performance.
• IP20 frontal protection and pollution degree 3 for safer operation.
• Certified to IEC/EN 60947 standards, plus UL508 and CSA approvals.

Technical Specification

• Number of poles: 3
• Pollution degree: 3
• IP degree (frontal): IP20
• Rated insulation voltage Ui (IEC/EN): 690 V
• Rated impulse withstand voltage Uimp: 6 kV
• Terminal tightening torque: 2 to 2.5 Nm
• Ith (IEC): 10 A
• Operating temperature: -25 to 60 °C
• Storage temperature: -50 to 70 °C
• Max altitude: 3000 m
• Weight: 160 g

What’s Included

• Lovato RFN380250 thermal overload relay
• Mounting and operation leaflet
• Protective packaging

Applications

• Three‑phase motor protection within the 1.6…2.5 A operating range
• Motor starter assemblies using Lovato BF09…BF38 contactors
• Industrial control panels requiring IEC/EN 60947‑compliant components
• Installations needing manual or automatic reset options for maintenance

Safety note: Install and commission only by qualified personnel. Isolate power before work, and select and apply the relay within the specified current range and ratings, following manufacturer instructions and applicable standards.
