R1D415 - EARTH LEAKAGE RELAY R1D 240-41 5VAC FLUS

Why Choose the R1D415?

Engineered for dependable residual current protection, the Lovato R1D415 Earth leakage relay combines Type A sensitivity with robust flush mounting for neat panels. Designed for use with an external toroidal transformer, this single-threshold relay operates across 110…125VAC/DC and 220…240/380…415VAC supplies, delivering fast, reliable detection of leakage faults to help prevent equipment damage and enhance operator safety in industrial and commercial installations.

Part of the R1D series, it meets IEC/EN 60947-2, supporting assured compliance. Built for longevity with a mechanical life of 50,000,000 cycles, it performs from -10 to +60 °C and stores at -20 to +80 °C. Installation is straightforward with flush mounting and terminals rated up to 0.5 Nm; compact 280 g construction suits dense panels and retrofit upgrades.

Key Benefits

• Type A residual characteristic for reliable leakage protection per IEC/EN 60947-2.
• Flush mounting delivers a clean, space-efficient panel appearance.
• External toroidal transformer enables flexible installation around existing conductors.
• Single operating threshold simplifies configuration and ongoing maintenance.
• Wide supply range suits 110…125VAC/DC and 220…240/380…415VAC systems.
• Robust mechanical life of 50000000 cycles for long-term service.
• Operates from -10 to +60 °C for varied environments.

Technical Specification

• Product type designation: R1D
• Terminal tightening torque (max): 0.5 Nm
• Mechanical life: 50000000 cycles
• Operating temperature: -10 to +60 °C
• Storage temperature: -20 to +80 °C
• Weight: 280 g

What’s Included

• Lovato R1D415 Earth leakage relay unit
• Installation and safety documentation

Applications

• Industrial control panels requiring residual current protection.
• LV switchboards and distribution panels in commercial buildings.
• OEM machinery and equipment panels with flush-mounted relays.
• Retrofit upgrades where external CTs simplify installation.

Safety note: Only qualified personnel should install and commission this product. Isolate power before work, use a compatible external toroidal transformer, tighten terminals to 0.5 Nm, and operate within the specified temperature range.
