PSL1M01024 LOVATO MOD 1PH POWER SUPPLY 10W 100-240VAC 24VDC
MPN: PSL1M01024
Special Price
£75.95
£63.29
Regular Price
£126.59
Why Choose the PSL1M01024?
Designed for compact control panels, the Lovato PSL1M01024 is a modular switching power supply delivering a stable 24 VDC at 0.42 A (10 W). This single-phase unit accepts a multivoltage 100...240 VAC input and installs quickly on DIN rail. Part of the PSL1M family, SKU PSL1M01024 suits OEMs and maintenance teams seeking a reliable, low-power DC source for instrumentation, controls and signalling.
Built for demanding environments, this 114 g supply operates from -40 to +71 °C and conforms to IEC/EN/BS 62368-1 and EMC standards IEC/EN/BS 61000-6-2/-6-3, with UL 508 and CSA C22.2 n°14 standards. Modular DIN-rail mounting streamlines panel integration, while Lovato’s sustainability certification supports responsible procurement. Ideal where dependable 24 VDC is required without occupying excessive space or complicating inventories.
Key Benefits
- Multivoltage 100...240 VAC input for global single-phase mains.
- Provides 24 VDC, 0.42 A output delivering 10 W to loads.
- Modular DIN rail mounting for fast, tidy panel installation.
- Wide operating temperature range from -40 to +71 °C.
- Lightweight 114 g design eases handling and panel layout.
- Conforms to IEC/EN/BS 62368-1 and EMC 61000-6-2/-6-3.
- Recognised to UL 508 and CSA C22.2 n°14 for wider acceptance.
Technical Specification
- Product type designation: PSL1M
- Operating temperature: -40 to +71 °C
- Storage temperature: -40 to +85 °C
- Weight: 114 g
What’s Included
- Lovato PSL1M01024 switching power supply unit
- Installation and safety leaflet
- Manufacturer datasheet (downloadable)
- Protective packaging for transit
Applications
- Control panels and OEM machine cabinets requiring 24 VDC
- PLC I/O, sensors and instrumentation power at the 10 W level
- Building automation, access control and signalling circuits
- Small auxiliary supplies in industrial and commercial enclosures
Frequently Asked Questions
What input voltage range does the PSL1M01024 accept?
It accepts multivoltage 100...240 VAC on a single-phase supply.
What is the DC output of this power supply?
It supplies 24 VDC at up to 0.42 A, providing 10 W.
How is the unit mounted in a panel?
It is designed for modular DIN rail mounting.
Can it operate in harsh temperature conditions?
Yes, it operates from -40 to +71 °C and can be stored from -40 to +85 °C.
Which standards does it conform to?
It conforms to IEC/EN/BS 62368-1, IEC/EN/BS 61000-6-2/-6-3, UL 508 and CSA C22.2 n°14.
Safety note: Install and commission only by qualified personnel. Isolate the mains supply before wiring, follow the manufacturer’s instructions and local regulations, and operate within the stated ratings and temperatures.
| Manufacturer Part Number | PSL1M01024 |
|---|---|
| Barcode | 8013975180280 |
| HS Code | 8504318090 |
| Manufacturer | Lovato |
| Output Voltage | 24VDC |
