PS-V10M ext.24V power supply 5,5-15kW

Why Choose the Yaskawa PS-V10M 24 V Power Supply Option?

The Yaskawa PS-V10M is a dedicated 24 V DC auxiliary control power supply option designed for use with Yaskawa V1000 AC inverter drives. It provides external control circuit power so the drive’s control electronics, operator display, communication functions and I/O status can remain available when the main drive power is removed or interrupted.

This power supply option is useful in automation systems where drive fault information, parameter data or network communication must remain accessible during a mains power loss. By maintaining power to the control circuit, the PS-V10M allows engineers and maintenance teams to monitor drive status without energising the main power circuit.

Designed for Yaskawa V1000 drive installations, the PS-V10M provides a 24 V DC input power connection for control circuit backup operation. It is commonly used with larger V1000 drive frames and supports reliable diagnostics, communications and control monitoring in industrial motor control systems.

Key Advantages

• Genuine Yaskawa 24 V auxiliary power option for V1000 drives.
• Maintains drive control circuit power during main supply loss.
• Allows fault data, parameter data and communication status to remain accessible.
• 24 V DC auxiliary control power input for backup operation.
• Designed for Yaskawa V1000 inverter drive systems.
• Compact option unit for direct integration with compatible drives.

Key Features

• Yaskawa PS-V10M 24 V power supply option.
• Designed for Yaskawa V1000 AC drives.
• 24 V DC auxiliary control power connection.
• Maintains control circuit power during mains interruption.
• Supports continued access to drive fault and parameter information.
• Helps keep network communications and I/O data operational.
• Supplied with option connection cable for compatible drive models.
• Designed for larger V1000 drive frame installations.

Technical Specifications

• Manufacturer: Yaskawa
• Model: PS-V10M
• Product type: 24 V DC auxiliary power supply option
• Application: V1000 drive control circuit backup power
• Compatible series: Yaskawa V1000 AC drives
• Compatible drive classes: 200 V and 400 V class V1000 drives
• Input voltage: 24 V DC
• Power function: Control circuit power only
• Main circuit power: Not supplied by this option
• Communication support: Helps maintain network communications during main power loss
• Diagnostic support: Allows access to fault and parameter data
• Installation type: Drive-mounted option unit
• Connection type: Option connection cable
• Related model: PS-V10S
• Typical use: Larger V1000 drive frames and control circuit backup applications

Reliable Control Power for V1000 Drive Systems

Inverter drives rely on their control circuits to store parameters, display fault information and communicate with automation systems. During a main power outage, a standard drive may lose access to this information until mains power is restored.

The Yaskawa PS-V10M provides auxiliary 24 V DC control power so the drive’s control section can remain active. This helps maintenance teams read faults, access parameters and maintain communication links while the main drive power remains isolated.

Typical Applications

• Yaskawa V1000 inverter drive installations.
• Control panels requiring drive communication during mains loss.
• Industrial automation systems with PLC or network monitoring.
• Fault diagnostics and maintenance applications.
• Machine building and OEM control systems.
• Control circuit backup power for compatible V1000 drives.

Trusted by Automation Engineers Worldwide

Yaskawa V1000 power options are widely used by automation engineers, panel builders and maintenance teams to improve drive monitoring, diagnostics and control circuit reliability in industrial motor control systems.
