Mersen Surge Protector Type 2 SPD 3 Pole 600 Volt D/C 20KA Y-PV
MPN: 83020138
Alt. SKU: STPT2-40K600V-YPV
Special Price
£111.16
£92.63
Regular Price
£150.42
Why Choose the STPT2-40K600V-YPV Surge Protection Device?
Engineered for photovoltaic systems up to 600V DC, the STPT2-40K600V-YPV offers robust Type 2 surge protection with a maximum discharge current of 40kA (8/20 μs), ensuring reliable defence against transient overvoltages.
This pluggable, 3-pole, 3-module SPD is designed for rapid installation and easy maintenance, providing enhanced safety and prolonged system life for critical PV installations.
Product Code: 83020138
Key Benefits
- High surge current capacity with 40kA maximum discharge current for superior protection.
- Pluggable design allows for quick installation and easy replacement.
- Three-pole configuration suitable for YPV system setups.
- Visual indication system for easy status monitoring (Green = OK, Not green = replace).
- Compact dimensions (54 mm width, 70 mm length, 90 mm height) save space in electrical panels.
- RoHS compliant and meets IEC Class II and UL Type 2 standards for safety and reliability.
Compatibility
The STPT2-40K600V-YPV is compatible with photovoltaic systems operating up to 600V DC, specifically designed for YPV system configurations. It integrates seamlessly with other photovoltaic and energy storage surge protection devices within the same product group.
Applications
- Photovoltaic (solar) power generation systems.
- Energy storage systems requiring DC surge protection.
- Industrial and commercial solar installations.
- Electrical panels and combiner boxes in PV arrays.
Technical Specifications
- Item number: 83020138
- Catalogue No: STPT2-40K600V-YPV
- Description: Surge Protection Device Type 2, 40kA Imax (8/20), Y PV, 600Vdc, Photovoltaic, 3 Poles, Pluggable, 3 Modules
- EAN/UPC Code: 8435297850144
- RoHS Compliant: Yes
- IEC SPD Type: Class II
- UL SPD Type: Type 2 Component Assembly
- Format: Pluggable
- AC or DC: DC
- Nominal Discharge Current (In) (8/20): 20 kA
- Max Discharge Current : Imax (8/20): 40 kA
- Protection Modes: L+/PE, L-/PE, L+/L-
- System Configuration: YPV
- Short Circuit Withstand (ISCPV): 10 kA
- Indication System: Yes
- Indication System Type: Green (OK) / Not green (replace)
- Torque Rating: 3 Nm
- Housing Material: PA66 CT1
- MOV Response Time: ≤25
- Up at In (L-PE): ≤2,6 kV
- MCOV DC+ DC-: 600 V
- MCOV DC+ G: 600 V
- MCOV DC- G: 600 V
- VPR DC+ DC-: 1800 V
- VPR DC+ G: 1800 V
- VPR DC- G: 1800 V
- Replacement Plug L1: 83020005
- Product Width: 54 mm
- Product Length: 70 mm
- Product Height: 90 mm
- Sell Pack Quantity: 1 EA
- Sell Pack Weight: 0.324 kg
- Sell Pack Width: 63 mm
- Sell Pack Length: 117 mm
- Sell Pack Height: 90 mm
- Product group: Photovoltaic & Energy Storage SPDs
- Product Weight: 0.284 kg
Frequently Asked Questions
What is the maximum voltage this SPD can handle?
The STPT2-40K600V-YPV is designed for photovoltaic systems up to 600V DC.
Can this device be replaced easily?
Yes, the pluggable design allows for quick and easy replacement without rewiring.
What indication does the device provide to show its status?
It features a green indication system to show normal operation; if the indicator is not green, the device should be replaced.
Is this SPD compliant with international standards?
Yes, it complies with IEC Class II and UL Type 2 Component Assembly standards.
Common Search Terms
SPD 600V DC, photovoltaic surge protector, Type 2 surge protection, pluggable SPD, solar panel surge device, YPV system surge protection, 40kA surge protector, Class II SPD, DC surge protector, energy storage SPD
| Manufacturer Part Number | 83020138 |
|---|---|
| Packed Quantity | 1 |
| Barcode | 8435297850144 |
| Height | 70mm |
| Width | 54mm |
| Depth | 90mm |
| HS Code | 85363090 |
| Country of Manufacture | Spain |
| Manufacturer | Mersen |
| Number of Poles | 3 Pole |
| Voltage | 600VDC |
| Maximum Continuous Voltage | 660V |
| Nominal Discharge Current | 20Ka |
| System Type | Y-PV |
| Alternative Product SKU | STPT2-40K600V-YPV |
Write Your Own Review
Protection system of coordinated stages: Type 1, 2 and 3 SPDs
The SPDs of a surge protection system must be able to withstand the discharged current and provide a Ures level (residua l voltage) lower than the Ue peak voltage that the equipment can withstand. Most of the times it is not possible to achieve this with just one SPD, especially because the intensity of the surge is not known, and because of the induction of overvoltages when conductors exceed 10m.
The optimal system of protection is the 3-STEP approach, in which successive stages are combined in the performance of high discharge capacity devices and devices with an optimal voltage protection level (low). This is addressed by the definition of "Types" or "Classes" of SPDs according to the type of transient pulses to which each protected zone in the installation is subject to.
