Mersen Surge Protector Type 2 SPD 3 Pole 1500 Volt D/C 10KA Y-P Volt Remote Indication
MPN: 83020159
Alt. SKU: STPT2-40K1500V-YPVM
Special Price
£185.32
£154.43
Regular Price
£247.09
Why Choose the STPT2-40K1500V-YPVM Surge Protection Device?
The STPT2-40K1500V-YPVM is a robust Type 2 surge protection device designed for photovoltaic applications up to 1500V DC. With an Imax of 40kA (8/20µs), it provides reliable protection for critical PV system components against transient overvoltages, enhancing system longevity and uptime.
Featuring a pluggable, three-pole design with three modules, this SPD allows rapid module replacement and minimises downtime. The integrated remote indication function ensures real-time monitoring for enhanced operational safety and maintenance efficiency.
Technical Specifications
- Item number: 83020159
- Catalogue No: STPT2-40K1500V-YPVM
- Description: Surge Protection Device Type 2, 40kA Imax (8/20), Y PV, 1500Vdc, Photovoltaic, 3 Poles, Pluggable, 3 Modules, Remote indication
- EAN/UPC Code: 8435297855033
- RoHS Compliant: Yes
- IEC SPD Type: Class II
- UL SPD Type: Type 2 Component Assembly
- Format: Pluggable
- AC or DC: DC
- Nominal Discharge Current (In) (8/20): 10 kA
- Max Discharge Current : Imax (8/20): 40 kA
- Protection Modes: L+/PE, L-/PE, L+/L-
- System Configuration: YPV
- Short Circuit Withstand (ISCPV): 10 kA
- Indication System: Yes
- Indication System Type: Green (OK) / Not green (replace) Microswitch
- Torque Rating: 3 Nm
- Housing Material: PA66 CT1
- MOV Response Time: ≤25
- Up at In (L-PE): ≤5 kV
- MCOV DC+ DC-: 1500 V
- MCOV DC+ G: 1500 V
- MCOV DC- G: 1500 V
- VPR DC+ DC-: 4000 V
- VPR DC+ G: 4000 V
- VPR DC- G: 4000 V
- Replacement Plug L1: 83020010
- Product Width: 54 mm
- Product Length: 70 mm
- Product Height: 90 mm
- Sell Pack Quantity: 1 EA
- Sell Pack Weight: 0.38 kg
- Sell Pack Width: 63 mm
- Sell Pack Length: 117 mm
- Sell Pack Height: 90 mm
- Product group: Photovoltaic & Energy Storage SPDs
- Product Weight: 0.34 kg
Product Code: STPT2-40K1500V-YPVM
Key Benefits
- High surge current capacity of 40kA ensures robust protection against transient overvoltages.
- Pluggable three-pole design with three modules allows quick and easy replacement, reducing downtime.
- Integrated remote indication function enables real-time monitoring and enhances maintenance efficiency.
- Suitable for photovoltaic systems up to 1500V DC, providing reliable protection for solar installations.
- Compact design with durable PA66 CT1 housing for long-term reliability in harsh environments.
Compatibility
This surge protection device is compatible with photovoltaic systems configured in YPV arrangement and designed for DC applications up to 1500V. It integrates seamlessly with Class II IEC and Type 2 UL SPD component assemblies, ensuring compliance with industry standards for solar energy installations.
Applications
- Photovoltaic solar power systems
- Renewable energy installations
- Energy storage systems
- Industrial DC power supply protection
- Electrical panels requiring Type 2 surge protection
Frequently Asked Questions
What is the maximum surge current this SPD can handle?
The STPT2-40K1500V-YPVM can handle a maximum surge current (Imax) of 40 kA (8/20 µs waveform).
Can this device be used in AC systems?
No, this SPD is designed specifically for DC applications, particularly photovoltaic systems up to 1500V DC.
How does the remote indication function work?
The device features a microswitch that changes from green (OK) to not green (replace) to signal the status, allowing remote monitoring of the SPD condition.
Is the device compliant with international standards?
Yes, it complies with IEC Class II and UL Type 2 Component Assembly standards.
Common Search Terms
surge protection device, SPD, photovoltaic surge protector, DC surge protector, Type 2 SPD, 1500V DC SPD, pluggable surge protector, solar panel surge protection, remote indication SPD, YPV surge protection
| Manufacturer Part Number | 83020159 |
|---|---|
| Packed Quantity | 1 |
| Barcode | 8435297855033 |
| Height | 70mm |
| Width | 54mm |
| Depth | 90mm |
| HS Code | 85363090 |
| Country of Manufacture | Spain |
| Manufacturer | Mersen |
| Number of Poles | 3 Pole |
| Voltage | 1500VDC |
| Maximum Continuous Voltage | 1500V |
| Nominal Discharge Current | 10Ka |
| Remote Indication | Yes |
| System Type | Y-PV |
| Alternative Product SKU | STPT2-40K1500V-YPVM |
Write Your Own Review
Protection system of coordinated stages: Type 1, 2 and 3 SPDs
The SPDs of a surge protection system must be able to withstand the discharged current and provide a Ures level (residua l voltage) lower than the Ue peak voltage that the equipment can withstand. Most of the times it is not possible to achieve this with just one SPD, especially because the intensity of the surge is not known, and because of the induction of overvoltages when conductors exceed 10m.
The optimal system of protection is the 3-STEP approach, in which successive stages are combined in the performance of high discharge capacity devices and devices with an optimal voltage protection level (low). This is addressed by the definition of "Types" or "Classes" of SPDs according to the type of transient pulses to which each protected zone in the installation is subject to.
