Mersen Surge Protector Type 2 SPD 1 Pole 400 Volt 20KA L-N Remote Indication
MPN: 83020111
Alt. SKU: STPT2-40K440V-1PM
This product is discontinued. Please view this replacement item.
Why Choose the Surge Protection Device Type 2, 40kA Imax, 1Ph, 400V, Pluggable?
The STPT2-40K440V-1PM delivers robust Type 2 surge protection, featuring a high discharge capacity of 40kA (8/20µs) for reliable safeguarding of single-phase installations up to 400V L-N. Its compact, single-module design ensures straightforward integration into existing DIN rail systems without compromising valuable panel space.
Engineered for maximum uptime, this 1-pole pluggable unit simplifies maintenance and enables rapid replacement. Remote indication provides immediate surge protection status for system monitoring, making it an ideal choice for critical industrial and commercial applications.
Technical Specifications
- Item number: 83020111
- Catalogue No: STPT2-40K440V-1PM
- Description: Surge Protection Device Type 2, 40kA Imax (8/20), 1Ph, 400V, L-N, 1 Pole, Pluggable, 1 Module, Remote indication
- EAN/UPC Code: 8435297850618
- RoHS Compliant: Yes
- IEC SPD Type: Class II
- UL SPD Type: Type 2 Component Assembly
- Format: Pluggable
- Nominal Operating Volt Rating (Un): 400
- AC or DC: AC
- Nominal Discharge Current (In) (8/20): 10 kA
- Max Discharge Current : Imax (8/20): 40 kA
- Protection Modes: L - N / L-PE / N-PE
- System Configuration: TNS, TNC, TT (only L-N)
- Short Circuit Withstand (ISCCR): 25 kA
- Indication System: Yes
- Indication System Type: Green (OK) / Not green (replace) Microswitch
- Number of Poles: 1-pole
- Torque Rating: 3 Nm
- Max. Back-Up Fuse: 125 A [gG]
- Housing Material: PA66 CT1
- MOV Response Time: ≤25
- Installation Mounting: DIN rail
- VPR L-N: 1500 V
- Replacement Plug L1: 83020004
- Product Width: 18 mm
- Product Length: 70 mm
- Product Height: 90 mm
- Sell Pack Quantity: 1 EA
- Sell Pack Weight: 0.163 kg
- Sell Pack Width: 24 mm
- Sell Pack Length: 117 mm
- Sell Pack Height: 90 mm
- Product group: Power Line SPDs
- Product Weight: 0.125 kg
Product Code: 83020111
Key Benefits
- High surge current capacity of 40kA (8/20µs) ensures superior protection against transient overvoltages.
- Compact, single-module design saves valuable DIN rail space in electrical panels.
- Pluggable format allows for easy installation and rapid replacement, minimising downtime.
- Remote indication feature enables real-time monitoring of device status for proactive maintenance.
- Suitable for single-phase 400V L-N systems, compatible with multiple system configurations (TNS, TNC, TT).
- Robust construction with PA66 CT1 housing ensures durability in industrial environments.
Compatibility
This surge protection device is compatible with single-phase electrical installations up to 400V L-N and supports system configurations including TNS, TNC, and TT (only L-N). It is designed for DIN rail mounting and can be integrated seamlessly into existing power distribution boards. Replacement plugs with catalogue number 83020004 are available for maintenance and upgrades.
Applications
- Industrial and commercial electrical distribution panels.
- Protection of sensitive electronic equipment from transient voltage spikes.
- Power supply systems requiring Type 2 surge protection compliance.
- Buildings with critical infrastructure demanding reliable surge protection and monitoring.
- Renewable energy installations and control panels.
Frequently Asked Questions
What is the maximum surge current this device can handle?
The device has a maximum discharge current (Imax) of 40kA (8/20µs), providing robust surge protection.
Can this SPD be used in three-phase systems?
This particular model is designed for single-phase (1-pole) systems up to 400V L-N and is not suitable for three-phase applications.
How does the remote indication work?
The device includes a microswitch that changes state when the SPD requires replacement, enabling remote monitoring of its operational status.
Is the device RoHS compliant?
Yes, the surge protection device complies with RoHS standards.
What type of mounting does this SPD require?
It is designed for DIN rail mounting, allowing easy integration into standard electrical panels.
Common Search Terms
Type 2 surge protector, 40kA surge protection device, pluggable SPD, 1 pole surge protector, 400V surge protector, DIN rail SPD, remote indication surge device, industrial surge protection, power line SPD
| Manufacturer Part Number | 83020111 |
|---|---|
| Packed Quantity | 1 |
| Barcode | 8435297850618 |
| Height | 70mm |
| Width | 18mm |
| Depth | 90mm |
| HS Code | 85363090 |
| Country of Manufacture | Spain |
| Manufacturer | Mersen |
| Number of Poles | 1 pole |
| Voltage | 400V |
| Maximum Continuous Voltage | 440V |
| Nominal Discharge Current | 20Ka |
| Remote Indication | Yes |
| System Type | L-N |
| Alternative Product SKU | STPT2-40K440V-1PM |
Write Your Own Review
Protection system of coordinated stages: Type 1, 2 and 3 SPDs
The SPDs of a surge protection system must be able to withstand the discharged current and provide a Ures level (residua l voltage) lower than the Ue peak voltage that the equipment can withstand. Most of the times it is not possible to achieve this with just one SPD, especially because the intensity of the surge is not known, and because of the induction of overvoltages when conductors exceed 10m.
The optimal system of protection is the 3-STEP approach, in which successive stages are combined in the performance of high discharge capacity devices and devices with an optimal voltage protection level (low). This is addressed by the definition of "Types" or "Classes" of SPDs according to the type of transient pulses to which each protected zone in the installation is subject to.
