Mersen Surge Protector Type 2+3 SPD 2 Pole 60 Volt 3KA TT/TNS Remote Indication
MPN: 83230509
Alt. SKU: STMT23-6K75V-SP-SM
Special Price
£74.26
£61.88
Regular Price
£99.01
Why Choose the STMT23-6K75V-SP-SM Surge Protection Device?
Engineered for robust protection in TT and TNS systems, this compact Type 2+3 Surge Protection Device handles surges up to 6kA (8/20 μs) with a maximum voltage of 60V, providing seamless defence for single-phase plus neutral installations.
Its slim, monobloc 1-module design saves space on DIN rails, while 2-pole configuration and remote indication ensure ease of integration, monitoring, and reliability in demanding industrial and commercial environments.
Product Code: 83230509
Key Benefits
- Compact slim monobloc design saves DIN rail space.
- High surge capacity with 6kA maximum discharge current.
- Effective protection for TT and TNS system configurations.
- Remote indication via microswitch for easy monitoring.
- Robust build suitable for industrial and commercial applications.
Compatibility
This SPD is compatible with single-phase plus neutral (1Ph+N) electrical installations in TT and TNS earthing systems. It integrates seamlessly with DIN rail mounting setups and supports systems requiring Type 2+3 surge protection.
Applications
- Industrial electrical distribution boards.
- Commercial building power protection.
- Renewable energy system surge defence.
- Control panels requiring compact surge protection.
- Single-phase plus neutral electrical installations.
Technical Specifications
- Item number: 83230509
- Catalogue No: STMT23-6K75V-SP-SM
- Description: Surge Protection Device Type 2+3, 6kA Imax (8/20), 1Ph+N, 60/-V, Slim, SP TT/TNS, 2 Poles, Monobloc, 1 Module, Remote indication
- EAN/UPC Code: 8435297850489
- RoHS Compliant: Yes
- IEC SPD Type: Class II + III
- Format: Slim Monobloc
- Nominal Operating Volt Rating (Un): 60
- AC or DC: AC
- Nominal Discharge Current (In) (8/20): 3 kA
- Max Discharge Current : Imax (8/20): 6 kA
- Protection Modes: L-N / L-PE
- System Configuration: TT, TNS
- Combined Discharge Voltage (1,2/50) (Uoc): 6 kV
- Short Circuit Withstand (ISCCR): 10 kA
- Design Details: Slim
- Indication System: Yes
- Indication System Type: Microswitch
- Number of Poles: 2-Pole
- Torque Rating: 0.7 Nm
- Max. Back-Up Fuse: 63 A [gG]
- Installation Mounting: DIN rail
- Uc (L-N): 75 V
- Up at In (N-PE): ≤0,9 kV
- Up at In (L-N): ≤0,5 kV
- Up at In (L-PE): ≤0,9 kV
- Product Width: 18 mm
- Product Length: 65 mm
- Product Height: 85 mm
- Sell Pack Quantity: 1 EA
- Sell Pack Weight: 0.087 kg
- Sell Pack Width: 24 mm
- Sell Pack Length: 117 mm
- Sell Pack Height: 90 mm
- Product group: Power Line SPDs
- Product Weight: 0.067 kg
Frequently Asked Questions
What systems is the STMT23-6K75V-SP-SM compatible with?
It is designed for TT and TNS earthing systems in single-phase plus neutral electrical installations.
What is the maximum surge current this device can handle?
The device can handle a maximum discharge current (Imax) of 6 kA (8/20 µs waveform).
Does this SPD provide remote indication?
Yes, it features a microswitch-based remote indication system for ease of monitoring.
How is the device mounted?
The SPD is designed for DIN rail mounting, allowing easy installation in electrical panels.
Common Search Terms
Surge protection device, SPD 6kA, Type 2+3 surge protector, TT system SPD, TNS system surge protection, DIN rail SPD, slim surge protector, remote indication SPD, industrial surge protection, commercial SPD
| Manufacturer Part Number | 83230509 |
|---|---|
| Packed Quantity | 1 |
| Barcode | 8435297850489 |
| Height | 65mm |
| Width | 18mm |
| Depth | 85mm |
| HS Code | 85363090 |
| Country of Manufacture | Spain |
| Manufacturer | Mersen |
| Number of Poles | 2 Pole |
| Voltage | 60V |
| Maximum Continuous Voltage | 75V |
| Nominal Discharge Current | 3Ka |
| Remote Indication | Yes |
| System Type | TT/TNS |
| Alternative Product SKU | STMT23-6K75V-SP-SM |
Write Your Own Review
Protection system of coordinated stages: Type 1, 2 and 3 SPDs
The SPDs of a surge protection system must be able to withstand the discharged current and provide a Ures level (residua l voltage) lower than the Ue peak voltage that the equipment can withstand. Most of the times it is not possible to achieve this with just one SPD, especially because the intensity of the surge is not known, and because of the induction of overvoltages when conductors exceed 10m.
The optimal system of protection is the 3-STEP approach, in which successive stages are combined in the performance of high discharge capacity devices and devices with an optimal voltage protection level (low). This is addressed by the definition of "Types" or "Classes" of SPDs according to the type of transient pulses to which each protected zone in the installation is subject to.
