Mersen Surge Protector Type 2+3 SPD 2 Pole 230 Volt 10KA TNS Remote Indication
MPN: 83230135
Alt. SKU: STPT23-20K275V-2P-LFM
Special Price
£68.16
£56.80
Regular Price
£90.88
Why Choose the Surge Protection Device Type 2+3, 20kA Imax (8/20), 2 Poles, Pluggable?
Engineered for robust protection, the STPT23-20K275V-2P-LFM effectively safeguards single-phase 230V installations against transient overvoltages, combining Type 2 and 3 SPD functionality in a compact, pluggable 2-module design. Its 20kA Imax (8/20) rating and leakage current free operation ensure reliable performance without nuisance tripping, ideal for demanding industrial and commercial environments.
Equipped with remote indication for proactive monitoring, this SPD is suitable for 2+0 TNS systems and offers straightforward installation with two poles. Choose this solution for maintenance efficiency, assured system uptime, and compliance with the latest surge protection standards.
Technical Specifications
- Item number: 83230135
- Catalogue No: STPT23-20K275V-2P-LFM
- Description: Surge Protection Device Type 2+3, 20kA Imax (8/20), 1Ph+N, 230/-V, Leakage current free, 2+0 TNS, 2 Poles, Pluggable, 2 Modules, Remote indication
- EAN/UPC Code: 8435297852353
- RoHS Compliant: Yes
- IEC SPD Type: Class II + III
- Format: Pluggable
- Nominal Operating Volt Rating (Un): 230
- AC or DC: AC
- Max Discharge Current : Imax (8/20): 20 kA
- Protection Modes: L-PE / N-PE
- System Configuration: TNS
- Combined Discharge Voltage (1,2/50) (Uoc): 10 kV
- Short Circuit Withstand (ISCCR): 25 kA
- Indication System: Yes
- Indication System Type: Green (OK) / Not green (replace) Microswitch
- Number of Poles: 2-Pole
- Torque Rating: 3 Nm
- Max. Back-Up Fuse: 63 A [gG]
- Housing Material: PA66 CT1
- MOV Response Time: ≤25
- Installation Mounting: DIN rail
- Replacement Plug N-PE: 83230003
- Replacement Plug L-N: 83230003
- Product Width: 36 mm
- Product Length: 70 mm
- Product Height: 90 mm
- Sell Pack Quantity: 1 EA
- Sell Pack Weight: 0.221 kg
- Sell Pack Width: 42 mm
- Sell Pack Length: 117 mm
- Sell Pack Height: 90 mm
- Product group: Power Line SPDs
- Product Weight: 0.191 kg
Product Code: STPT23-20K275V-2P-LFM
Key Benefits
- High surge current capacity of 20kA ensures robust protection against transient overvoltages.
- Leakage current free design prevents nuisance tripping and enhances system reliability.
- Compact, pluggable 2-module format allows for easy installation and maintenance.
- Remote indication feature enables proactive monitoring of device status.
- Suitable for 2+0 TNS systems, ensuring compatibility with common industrial configurations.
- Compliance with IEC Class II + III standards guarantees high safety and performance.
Compatibility
This surge protection device is compatible with single-phase 230V AC systems configured as 2+0 TNS. It is designed to be mounted on standard DIN rails and can be integrated easily into existing electrical distribution boards. The device supports protection modes L-PE and N-PE and is suitable for systems using up to 63 A back-up fuses.
Applications
- Industrial and commercial electrical installations requiring reliable surge protection.
- Single-phase 230V distribution boards in manufacturing plants and office buildings.
- Protection of sensitive electronic equipment from transient voltage spikes.
- Systems where remote status indication is necessary for maintenance and monitoring.
- Environments demanding compliance with IEC surge protection standards.
Frequently Asked Questions
What does the 20kA Imax rating signify?
The 20kA Imax rating indicates the maximum surge current the device can safely divert without damage, measured using an 8/20 microsecond waveform.
Is this SPD suitable for three-phase systems?
No, this specific model is designed for single-phase (1Ph+N) 230V systems with a 2+0 TNS configuration.
What is the purpose of the remote indication feature?
The remote indication allows the device to signal its operational status to a remote monitoring system, enabling timely maintenance or replacement.
Can this device be installed on any DIN rail?
Yes, it is designed for standard DIN rail mounting, making installation straightforward in most electrical panels.
Common Search Terms
surge protection device, SPD Type 2+3, 20kA surge protector, pluggable SPD, single-phase surge protector, 230V surge protection, DIN rail SPD, remote indication surge protector, industrial surge protector, TNS system SPD
| Manufacturer Part Number | 83230135 |
|---|---|
| Packed Quantity | 1 |
| Barcode | 8435297852353 |
| Height | 70mm |
| Width | 36mm |
| Depth | 90mm |
| HS Code | 85363090 |
| Country of Manufacture | Spain |
| Manufacturer | Mersen |
| Number of Poles | 2 Pole |
| Voltage | 230V |
| Maximum Continuous Voltage | 275V |
| Nominal Discharge Current | 10Ka |
| Remote Indication | Yes |
| System Type | TNS |
| Alternative Product SKU | STPT23-20K275V-2P-LFM |
Write Your Own Review
Protection system of coordinated stages: Type 1, 2 and 3 SPDs
The SPDs of a surge protection system must be able to withstand the discharged current and provide a Ures level (residua l voltage) lower than the Ue peak voltage that the equipment can withstand. Most of the times it is not possible to achieve this with just one SPD, especially because the intensity of the surge is not known, and because of the induction of overvoltages when conductors exceed 10m.
The optimal system of protection is the 3-STEP approach, in which successive stages are combined in the performance of high discharge capacity devices and devices with an optimal voltage protection level (low). This is addressed by the definition of "Types" or "Classes" of SPDs according to the type of transient pulses to which each protected zone in the installation is subject to.
