MERSEN FUSE FUS. AM NH1 C/P 80A NH1AM69V80P-2
MPN: C217720
Alt. SKU: NH1AM69V80P-2
Special Price
£26.93
£22.44
Regular Price
£48.96
MERSEN FUSE FUS. AM NH1 C/P 80A NH1AM69V80P-2 is available to buy in increments of 3
Why Choose the DIN NH Standard Fuse-Link aM Size NH1 690VAC 80A Live Tags Striker Body Width 44.60 mm NH1AM69V80P-2?
This high-performance NH fuse-link is engineered for industrial motor protection up to 690VAC, delivering reliable short-circuit protection with a rated current of 80A. Its aM characteristic ensures precision safeguarding of motor circuits against overload and fault conditions.
Featuring live tags and an integrated striker for signalling, the robust 44.60 mm wide NH1 body facilitates straightforward installation and secure operation in demanding environments. Manufactured to DIN standards, it assures compatibility and durability for critical power distribution applications.
Technical Specifications
- Item number: C217720
- Catalogue No: NH1AM69V80P-2
- Description: DIN NH Standard fuse-link aM Size NH1 690VAC 80A live tags Striker Body width 44.60 mm
- EAN/UPC Code: 8430399012742
- Rated voltage AC IEC: 690 V
- Ampere Rating: 80 A
- RoHS Compliant: Yes
- AC or DC: AC
- Speed/Characteristic: aM
- Fuse Size: NH1
- Mounting: Clip
- AC Max I.R./Breaking Capacity: I1: 80 kA
- Design Details: live tags
- Indication System: Yes
- Indication System Type: Striker
- Connection/Terminal Material: Silver-Plated Copper
- Connection/Terminal Type: Plain Blades
- Product Width: 44.6 mm
- Product Length: 135 mm
- Product Height: 64 mm
- Sell Pack Quantity: 3 EA
- Sell Pack Weight: 1.1499 kg
- Sell Pack Width: 130 mm
- Sell Pack Length: 140 mm
- Sell Pack Height: 70 mm
- Product group: Low Voltage IEC Fuses
- Body/Insulating Material: Ceramic
- Product Weight: 0.3833 kg
- Power Dissipation at Rated Current Value: 6 W
Product Code: NH1AM69V80P-2
Key Benefits
- Reliable motor protection with precise aM characteristic
- High breaking capacity of 80 kA ensures safety during faults
- Live tags and striker indication system for clear fault signalling
- Robust ceramic body for durability in industrial environments
- Easy clip mounting for quick installation and replacement
Compatibility
This NH1 fuse-link is compatible with standard DIN NH fuse holders and switchgear designed for NH1 size fuses, supporting applications up to 690VAC and 80A. Its standardised dimensions and connection types ensure seamless integration into existing low voltage IEC fuse systems.
Applications
- Industrial motor circuit protection
- Power distribution panels
- Control and automation systems
- Short-circuit and overload protection in manufacturing plants
- Heavy machinery electrical safety
Frequently Asked Questions
What does the aM characteristic mean?
The aM characteristic indicates the fuse is designed for motor protection, allowing short-time current surges during motor start-up while providing protection against overload and short circuits.
Can this fuse-link be used in DC circuits?
No, this fuse-link is rated for AC applications only, as specified in its technical specifications.
How does the striker indication system work?
The striker indication system provides a mechanical signal when the fuse operates, allowing quick visual identification of a blown fuse without disassembly.
Is this fuse RoHS compliant?
Yes, the product meets RoHS compliance standards, ensuring it is free from hazardous substances.
Common Search Terms
NH1 fuse-link, DIN NH fuse 80A, motor protection fuse, 690V fuse-link, aM characteristic fuse, ceramic NH fuse, live tags fuse, striker indication fuse, industrial motor fuse, low voltage IEC fuse
| Manufacturer Part Number | C217720 |
|---|---|
| Packed Quantity | 3 |
| Barcode | 8430399012742 |
| Height | 135mm |
| Width | 44.6mm |
| Depth | 64mm |
| HS Code | 85361090 |
| Manufacturer | Mersen |
| Alternative Product SKU | NH1AM69V80P-2 |
