MERSEN FUSE CC6,621 CP GRB 27.60 6,3 CC6,621CPGRB27.606,3
MPN: Z098600
Alt. SKU: FD27GB66V6,3T
Special Price
£54.86
£45.72
Regular Price
£84.41
MERSEN FUSE CC6,621 CP GRB 27.60 6,3 CC6,621CPGRB27.606,3 is available to buy in increments of 10
Why Choose the High-Speed Cylindrical Fuse Protistor® Size 27x60 gR 660VDC IEC 6.3A With Striker FD27GB66V6,3T?
Engineered for reliable protection of DC circuits up to 660V, this Protistor® fuse features a fast-acting gR (gRB) characteristic that ensures rapid interruption of fault currents, safeguarding sensitive equipment and enhancing operational safety.
The integral striker function provides remote indication of fuse operation, enabling efficient maintenance and system monitoring. Designed to IEC standards, the robust 27x60mm format guarantees compatibility and durability for demanding industrial applications.
Product Code: Z098600
Key Benefits
- Fast-acting gR characteristic for superior protection of semiconductor devices.
- Integral striker for remote indication of fuse operation, facilitating quick maintenance.
- High breaking capacity of 50 kA DC ensures safe interruption of fault currents.
- Robust ceramic body material for enhanced durability and reliability.
- Silver-plated copper terminals with ferrule connection for excellent conductivity and secure mounting.
- Compliant with IEC standards and RoHS directives.
Compatibility
This fuse is compatible with industrial DC circuits requiring high-speed protection up to 660 VDC, particularly semiconductor protection applications. It fits standard size 27x60 fuse holders with clip mounting and is suitable for systems using ferrule terminal connections.
Applications
- Protection of semiconductor devices such as thyristors and diodes.
- DC power supplies and converters in industrial automation.
- Renewable energy systems including photovoltaic installations.
- Battery protection in uninterruptible power supplies (UPS).
- General industrial DC circuit protection requiring high breaking capacity.
Technical Specifications
- Item number: Z098600
- Catalogue No: FD27GB66V6,3T
- Description: High-Speed Cylindrical Fuse Protistor® Size 27x60 gR (gRB) 660VDC IEC 6.3A With Striker
- EAN/UPC Code: 3605340155310
- Rated voltage DC IEC: 660 V
- Ampere Rating: 6.3 A
- RoHS Compliant: Yes
- AC or DC: DC
- Speed/Characteristic: gR
- Fuse Size: 27x60
- Mounting: Clip
- Max. Rated Breaking Capacity DC: 50 kA
- Design Details: gRB
- Indication System: Yes
- Indication System Type: Striker
- Connection/Terminal Material: Silver-Plated Copper
- Connection/Terminal Type: Ferrule
- Product Diameter: 27 mm
- Product Length: 60.3 mm
- Sell Pack Quantity: 10 EA
- Sell Pack Weight: 0.8 kg
- Sell Pack Width: 123 mm
- Sell Pack Length: 138 mm
- Sell Pack Height: 30 mm
- Product group: Semiconductor Protection Fuses
- Body/Insulating Material: Ceramic
- Product Weight: 0.08 kg
- Power Dissipation at Rated Current Value: 1.3 W
Frequently Asked Questions
What does the gR characteristic mean?
The gR characteristic indicates a full-range semiconductor fuse that provides protection against both overload and short-circuit currents, designed specifically for semiconductor devices.
What is the purpose of the striker indication system?
The striker provides a mechanical indication that the fuse has operated (blown), allowing remote signalling and easier maintenance without the need for visual inspection.
Is this fuse suitable for AC circuits?
No, this fuse is designed specifically for DC applications up to 660 VDC and may not provide appropriate protection in AC circuits.
Can this fuse be used in photovoltaic systems?
Yes, its high DC breaking capacity and fast-acting characteristic make it suitable for protecting photovoltaic and other renewable energy systems.
Common Search Terms
High-speed fuse, cylindrical fuse 27x60, Protistor fuse, semiconductor protection fuse, DC fuse 660V, gR fuse, fuse with striker, industrial DC fuse, fast-acting fuse 6.3A, IEC fuse size 27x60
| Manufacturer Part Number | Z098600 |
|---|---|
| Packed Quantity | 10 |
| Barcode | 3605340155310 |
| Height | 60.3mm |
| Width | 27mm |
| Depth | 27mm |
| HS Code | 85361010 |
| Country of Manufacture | France |
| Manufacturer | Mersen |
| Alternative Product SKU | FD27GB66V6,3T |
