MERSEN FUSE BTIS42V100M160 A3 BTIS42V100M160
MPN: Q1019190
Alt. SKU: BTIS42V100M160
Special Price
£8.63
£7.19
Regular Price
£24.65
MERSEN FUSE BTIS42V100M160 A3 BTIS42V100M160 is available to buy in increments of 10
Why Choose the BS88 gM Type A3 415VAC 240VDC 100M160A BTIS Offset Tag BTIS42V100M160?
Engineered to IEC BS88 standards, the BTIS42V100M160 fuse-link offers reliable protection for circuits rated up to 415VAC and 240VDC, with a current capacity of 100A to 160A. Its gM characteristic ensures effective handling of both overloads and short-circuit conditions, maximising system safety and minimising downtime.
The offset tag configuration provides straightforward installation and secure connectivity, making it ideal for panel builders and OEM applications. Trust the BTIS42V100M160 for robust, compliant performance in demanding industrial environments.
Product Code: BTIS42V100M160
Key Benefits
- Complies with IEC BS88 standards ensuring high safety and reliability.
- gM characteristic provides comprehensive protection against overloads and short circuits.
- Offset tag terminals allow easy and secure bolted mounting.
- Suitable for both AC (415V) and DC (240V) applications.
- Ceramic body offers excellent insulating properties and durability.
- High breaking capacity: 80 kA AC and 40 kA DC for demanding industrial environments.
Compatibility
The BTIS42V100M160 fuse-link is compatible with A3 size fuse holders and switchgear designed for IEC BS88 gM type fuses. It is suitable for use in low voltage industrial electrical panels and systems requiring bolted offset tag connections.
Applications
- Industrial motor protection circuits.
- Power distribution panels and switchgear.
- OEM equipment requiring robust fuse protection.
- Control panels in manufacturing plants.
- Renewable energy systems with DC protection needs.
Technical Specifications
- Item number: Q1019190
- Catalogue No: BTIS42V100M160
- Description: British Standard fuse-link IEC BS88 gM Type A3 415VAC 240VDC 100M160A BTIS Offset Tag
- EAN/UPC Code: 3605340516975
- Rated voltage AC IEC: 415 V
- Rated voltage DC IEC: 240 V
- In M Ich: 100M160 A
- RoHS Compliant: Yes
- AC or DC: AC/DC
- Speed/Characteristic: gM
- Fuse Size: A3
- Mounting: Bolted
- Clearing I2t At Rated Voltage: 168000 A²s
- Melting I2t: 60000 A²s
- AC Max I.R./Breaking Capacity: I1: 80 kA
- Max. Rated Breaking Capacity DC: 40 kA
- Connection/Terminal Material: Tin-Plated Copper
- Connection/Terminal Type: Offset Tag
- Product Diameter: 26.9 mm
- Product Width: 28 mm
- Product Length: 88.5 mm
- Sell Pack Quantity: 10 EA
- Sell Pack Weight: 0.88 kg
- Sell Pack Width: 98 mm
- Sell Pack Length: 140 mm
- Sell Pack Height: 62 mm
- Product group: Low Voltage IEC Fuses
- Body/Insulating Material: Ceramic
- Product Weight: 0.088 kg
- Power Dissipation at Rated Current Value: 8.8 W
Frequently Asked Questions
What does the gM characteristic mean?
The gM characteristic indicates that the fuse is suitable for the protection of motor circuits and associated cables, providing full-range protection against overloads and short circuits.
Can this fuse be used in DC applications?
Yes, the BTIS42V100M160 is rated for up to 240V DC, making it suitable for certain DC circuit protection applications.
What type of mounting does this fuse require?
This fuse features offset tag terminals designed for bolted mounting, ensuring secure and reliable connections.
Is this fuse RoHS compliant?
Yes, the BTIS42V100M160 fuse-link is RoHS compliant, meeting environmental and safety standards.
Common Search Terms
BS88 fuse, gM fuse-link, IEC fuse A3 size, 100A 160A fuse, 415V AC fuse, 240V DC fuse, offset tag fuse, industrial fuse-link, bolted mounting fuse, ceramic fuse
| Manufacturer Part Number | Q1019190 |
|---|---|
| Packed Quantity | 10 |
| Barcode | 3605340516975 |
| Height | 88.5mm |
| Width | 28mm |
| Depth | 26.9mm |
| HS Code | 85361090 |
| Country of Manufacture | India |
| Manufacturer | Mersen |
| Alternative Product SKU | BTIS42V100M160 |
