MERSEN FUSE BLD24V25 BLD24V25
MPN: R1065697
Alt. SKU: BLD24V25
£4.57
£3.81
MERSEN FUSE BLD24V25 BLD24V25 is available to buy in increments of 10
Why Choose the BS88 gG Type 13x29 25A Fuse-Link?
Engineered to IEC and BS88 standards, this gG type fuse-link (13x29 mm) offers reliable circuit protection for low and medium voltage electrical systems up to 240VAC. With a rated current of 25A, it ensures effective safeguarding of cables and equipment against overloads and short circuits.
Ideal for industrial and commercial applications, the BLD24V25 fuse-link delivers consistent performance, rapid fault interruption, and effortless integration into BS88-compatible fuse holders, supporting safe and dependable operation across demanding environments.
Technical Specifications
- Item number: R1065697
- Catalogue No: BLD24V25
- Description: British Standard fuse-link IEC BS88 gG Type 13x29 240VAC 25A
- EAN/UPC Code: 3605340607178
- Rated voltage AC IEC: 240 V
- Ampere Rating: 25 A
- RoHS Compliant: Yes
- AC or DC: AC
- Speed/Characteristic: gG
- Fuse Size: 13x29
- Mounting: Clip
- Clearing I2t At Rated Voltage: 1563 A²s
- Melting I2t: 625 A²s
- AC Max I.R./Breaking Capacity: I1: 16.5 kA
- Connection/Terminal Material: Copper
- Connection/Terminal Type: Cylindrical
- Product Diameter: 12.7 mm
- Product Length: 29 mm
- Sell Pack Quantity: 10 EA
- Sell Pack Weight: 0.108 kg
- Sell Pack Width: 70 mm
- Sell Pack Length: 40 mm
- Sell Pack Height: 35 mm
- Product group: Low Voltage IEC Fuses
- Body/Insulating Material: Ceramic
- Product Weight: 0.0108 kg
- Power Dissipation at Rated Current Value: 2.14 W
Product Code: R1065697
Key Benefits
- Complies with IEC and BS88 standards for assured quality and safety.
- High breaking capacity of 16.5 kA for effective fault interruption.
- Ceramic body ensures durability and heat resistance.
- Compact 13x29 mm size for easy integration in standard fuse holders.
- Copper cylindrical terminals provide reliable electrical connection.
- RoHS compliant, supporting environmental safety standards.
Compatibility
This fuse-link is compatible with all BS88 standard fuse holders designed for 13x29 mm gG type fuses. It is suitable for use in low voltage AC circuits up to 240 V, making it ideal for integration in industrial and commercial electrical distribution panels and equipment.
Applications
- Industrial machinery protection
- Commercial electrical distribution systems
- Motor control circuits
- Lighting and power circuits
- General electrical equipment safeguarding
Frequently Asked Questions
What does the gG rating mean on this fuse-link?
The gG rating indicates that the fuse-link is a general purpose fuse suitable for protection of cables and equipment against overloads and short circuits in AC circuits.
Can this fuse-link be used in DC applications?
No, this fuse-link is designed specifically for AC applications up to 240 V and is not suitable for DC circuits.
What is the significance of the 16.5 kA breaking capacity?
The 16.5 kA breaking capacity represents the maximum fault current the fuse can safely interrupt without damage, ensuring protection during high short circuit events.
Is this fuse RoHS compliant?
Yes, this fuse-link complies with RoHS directives, ensuring it is free from hazardous substances.
Common Search Terms
BS88 fuse, 13x29 fuse-link, 25A fuse, gG fuse, IEC fuse-link, ceramic fuse, low voltage fuse, industrial fuse, 240V fuse, copper terminal fuse
| Manufacturer Part Number | R1065697 |
|---|---|
| Packed Quantity | 10 |
| Barcode | 3605340607178 |
| Height | 29mm |
| Width | 12.7mm |
| Depth | 12.7mm |
| HS Code | 85361050 |
| Country of Manufacture | India |
| Manufacturer | Mersen |
| Alternative Product SKU | BLD24V25 |
