MERSEN FUSE BLD24V20 BLD24V20
MPN: Q1065696
Alt. SKU: BLD24V20
£4.57
£3.81
MERSEN FUSE BLD24V20 BLD24V20 is available to buy in increments of 10
Why Choose the BS88 gG Type 13x29 Fuse-Link 240VAC 20A BLD24V20?
This BS88 gG Type 13x29 fuse-link is engineered for reliable circuit protection in industrial and commercial electrical installations, supporting up to 240VAC and 20A. Its compact design facilitates straightforward integration into existing fuse carriers, ensuring compatibility with standard BS88 fuse holders.
Manufactured to stringent IEC and British Standards, the BLD24V20 delivers consistent performance and fast-acting response to overloads and short circuits, reducing downtime and safeguarding valuable equipment. Ideal for cost-effective protection in critical power distribution applications.
Product Code: Q1065696
Key Benefits
- Reliable protection against overloads and short circuits up to 20A at 240VAC
- Compact 13x29 mm size for easy integration into standard BS88 fuse holders
- High breaking capacity of 16.5 kA ensures safety in industrial environments
- Ceramic body provides excellent insulation and durability
- Compliance with IEC and British Standards for assured quality and performance
- Low power dissipation of 1.54 W minimises energy loss during operation
Compatibility
The BLD24V20 fuse-link is compatible with standard BS88 fuse carriers and holders designed for 13x29 mm fuse sizes. It is suitable for use in low voltage IEC fuse applications requiring gG characteristic fuses rated for 240 V AC circuits.
Applications
- Industrial motor protection circuits
- Power distribution panels in commercial buildings
- Control and automation systems
- General electrical installations requiring reliable overcurrent protection
- Renewable energy systems and power inverters
Technical Specifications
- Item number: Q1065696
- Catalogue No: BLD24V20
- Description: British Standard fuse-link IEC BS88 gG Type 13x29 240VAC 20A
- EAN/UPC Code: 3605340607161
- Rated voltage AC IEC: 240 V
- Ampere Rating: 20 A
- RoHS Compliant: Yes
- AC or DC: AC
- Speed/Characteristic: gG
- Fuse Size: 13x29
- Mounting: Clip
- Clearing I2t At Rated Voltage: 1148 A²s
- Melting I2t: 459 A²s
- AC Max I.R./Breaking Capacity: I1: 16.5 kA
- Connection/Terminal Material: Copper
- Connection/Terminal Type: Cylindrical
- Product Diameter: 12.7 mm
- Product Length: 29 mm
- Sell Pack Quantity: 10 EA
- Sell Pack Weight: 0.108 kg
- Sell Pack Width: 70 mm
- Sell Pack Length: 40 mm
- Sell Pack Height: 35 mm
- Product group: Low Voltage IEC Fuses
- Body/Insulating Material: Ceramic
- Product Weight: 0.0108 kg
- Power Dissipation at Rated Current Value: 1.54 W
Frequently Asked Questions
What does the gG characteristic mean for this fuse?
The gG characteristic indicates that the fuse is a general purpose fuse-link suitable for protection of cables and electrical equipment against overloads and short circuits.
Is this fuse suitable for DC applications?
No, this particular fuse-link is rated for AC use only, as specified by its 240 V AC rating.
Can I use this fuse in a different fuse holder size?
No, the BLD24V20 is designed specifically for 13x29 mm fuse holders and may not fit or perform correctly in other sizes.
What is the breaking capacity of this fuse?
The fuse has a maximum breaking capacity of 16.5 kA at rated voltage, ensuring safe interruption of high fault currents.
Common Search Terms
BS88 fuse-link, 13x29 fuse, 20A fuse, 240V fuse, gG fuse, industrial fuse, IEC fuse, ceramic fuse-link, low voltage fuse, circuit protection fuse
| Manufacturer Part Number | Q1065696 |
|---|---|
| Packed Quantity | 10 |
| Barcode | 3605340607161 |
| Manufacturer | Mersen |
| Alternative Product SKU | BLD24V20 |
