MERSEN FUSE 690V NH0 C/P gG 32A NH0GG69V32P-2
MPN: P213637
Alt. SKU: NH0GG69V32P-2
Special Price
£24.38
£20.32
Regular Price
£44.33
MERSEN FUSE 690V NH0 C/P gG 32A NH0GG69V32P-2 is available to buy in increments of 3
Why Choose the DIN NH Standard Fuse-Link gG Size NH0 690VAC 32A Live Tags Striker Body Width 41.30 mm NH0GG69V32P-2?
This DIN NH standard fuse-link provides reliable circuit protection for industrial and commercial electrical systems, supporting operational voltages up to 690VAC and rated at 32A. Designed with live tags and an integrated striker, it ensures secure installation and facilitates straightforward fuse monitoring and replacement.
With a compact NH0 size and a body width of 41.30 mm, this fuse-link is ideal for space-limited switchgear and panel designs. Manufactured to strict quality standards, it delivers consistent performance, safety, and compatibility with industry-standard NH fuse bases.
Technical Specifications
- Item number: P213637
- Catalogue No: NH0GG69V32P-2
- Description: DIN NH Standard fuse-link gG Size NH0 690VAC 32A live tags Striker Body width 41.30 mm
- EAN/UPC Code: 8430399012223
- Rated voltage AC IEC: 690 V
- Ampere Rating: 32 A
- RoHS Compliant: Yes
- AC or DC: AC
- Speed/Characteristic: gG
- Fuse Size: NH0
- Mounting: Clip
- AC Max I.R./Breaking Capacity: I1: 80 kA
- Design Details: live tags
- Indication System: Yes
- Indication System Type: Striker
- Connection/Terminal Material: Silver-Plated Copper
- Connection/Terminal Type: Plain Blades
- Product Width: 41.3 mm
- Product Length: 125 mm
- Product Height: 59.5 mm
- Sell Pack Quantity: 3 EA
- Sell Pack Weight: 0.825 kg
- Sell Pack Width: 130 mm
- Sell Pack Length: 132 mm
- Sell Pack Height: 64 mm
- Product group: Low Voltage IEC Fuses
- Body/Insulating Material: Ceramic
- Product Weight: 0.275 kg
- Power Dissipation at Rated Current Value: 3.7 W
Product Code: NH0GG69V32P-2
Key Benefits
- High breaking capacity of 80 kA ensures robust protection against short circuits.
- Live tags and striker indication system facilitate safe and easy fuse status monitoring and replacement.
- Compact NH0 size with a slim 41.3 mm width fits well in space-constrained installations.
- Silver-plated copper terminals provide excellent conductivity and corrosion resistance.
- Ceramic body offers superior insulation and thermal stability for enhanced safety.
Compatibility
This fuse-link is compatible with standard NH fuse bases designed for NH0 size fuses and supports mounting via clip connection. It is suitable for use in low voltage IEC fuse systems and integrates seamlessly into industrial and commercial switchgear panels operating at voltages up to 690VAC.
Applications
- Protection of electrical circuits in industrial machinery and equipment.
- Use in commercial building electrical distribution panels.
- Integration into switchgear for motor and transformer protection.
- General low voltage electrical circuit protection requiring gG characteristic fuses.
Frequently Asked Questions
What does the gG characteristic mean for this fuse?
The gG characteristic indicates that this fuse is a general-purpose fuse-link suitable for protection of cables and conductors against overload and short-circuit currents.
Can this fuse-link be used in DC circuits?
No, this fuse is designed specifically for AC applications up to 690 V as indicated in the specifications.
How does the striker indication system work?
The striker indication system provides a mechanical signal when the fuse has blown, allowing for quick visual identification without disassembling the panel.
Is this fuse RoHS compliant?
Yes, this product meets RoHS compliance standards, ensuring it is free from hazardous substances.
Common Search Terms
DIN NH fuse-link, NH0 fuse 32A, 690VAC fuse-link, gG fuse NH0 size, live tag fuse, striker fuse indicator, ceramic body fuse, industrial fuse-link, low voltage fuse, clip mount fuse
| Manufacturer Part Number | P213637 |
|---|---|
| Packed Quantity | 3 |
| Barcode | 8430399012223 |
| Height | 125mm |
| Width | 41.3mm |
| Depth | 59.5mm |
| HS Code | 85361050 |
| Country of Manufacture | Hungary |
| Manufacturer | Mersen |
| Alternative Product SKU | NH0GG69V32P-2 |
