MERSEN FUSE 60A J 2P ULTRASAFE US6J2
MPN: US6J2
Special Price
£66.58
£55.48
Regular Price
£121.04
MERSEN FUSE 60A J 2P ULTRASAFE US6J2 is available to buy in increments of 3
Why Choose the Fuse Holder UltraSafe™ 600VAC 600VDC Class J 60A 2-Pole Pressure Plate IP65?
The UltraSafe™ Class J Fuse Holder supports up to 60A at 600VAC/DC, providing robust and reliable circuit protection in demanding industrial applications. Its 2-pole design allows secure installation of Class J fuses for effective isolation and streamlined maintenance.
Engineered with a pressure plate connection and IP65 sealing, this fuse holder ensures safe, tool-friendly wiring and resistance to dust and water ingress, making it ideal for harsh environments. Select for elevated safety, operational efficiency, and compliance with rigorous industrial standards.
Technical Specifications
- Item number: US6J2
- Description: Fuse Holder UltraSafe™ 600VAC 600VDC Class J 60A 2-Pole Pressure Plate IP65
- EAN/UPC Code: 782001830878
- Rated voltage AC UL: 600 V
- Rated voltage DC UL: 600 V
- Frequency (Hz): 50/60 Hz
- Ampere Rating: 60 A
- RoHS Compliant: Yes
- AC or DC: AC/DC
- Fuse Class: Class J
- Short Circuit Current Rating (SCCR): 200 kA
- Fuse Type/Class: Class J
- Number of Poles: 2-Pole
- Wiring range: #2 to 14 AWG
- Fuse Installation Method: Clip-in
- Torque Rating: 5.084 Nm
- Max Fuse Rating: 60 A
- Installation Mounting: DIN rail
- Product Width: 80 mm
- Product Length: 121.9 mm
- Product Height: 88.9 mm
- Sell Pack Quantity: 3 EA
- Sell Pack Weight: 1.7418 kg
- Sell Pack Width: 130 mm
- Sell Pack Length: 260.1 mm
- Sell Pack Height: 95 mm
- Product group: Fuse Holders
- Body/Insulating Material: Polyamide
- Product Weight: 0.5534 kg
Product Code: US6J2
Key Benefits
- Supports both AC and DC voltages up to 600V for versatile applications.
- High ampere rating of 60A ensures reliable circuit protection.
- IP65 rating provides excellent dust and water ingress protection for harsh environments.
- Pressure plate connection allows for secure, tool-friendly wiring.
- Clip-in fuse installation method simplifies maintenance and replacement.
- Durable polyamide body offers robust insulation and mechanical strength.
- Compact DIN rail mounting for easy integration into electrical panels.
Compatibility
This fuse holder is compatible with Class J fuses rated up to 60A and supports wiring ranges from #2 to 14 AWG. It is suitable for use in industrial control panels, motor control centres, and other electrical distribution systems requiring Class J fuse protection.
Applications
- Industrial motor control and protection circuits.
- Power distribution panels and switchgear.
- Renewable energy systems requiring DC fuse protection.
- Harsh environment electrical enclosures needing IP65 protection.
- General industrial machinery and equipment safety.
Frequently Asked Questions
What types of fuses can be used with this fuse holder?
The UltraSafe™ fuse holder is designed specifically for Class J fuses rated up to 60A.
Is this fuse holder suitable for outdoor use?
Yes, with an IP65 rating, it provides protection against dust and water jets, making it suitable for many outdoor and harsh environment applications.
What is the wiring range supported by this fuse holder?
The wiring range supported is from #2 to 14 AWG, accommodating a variety of conductor sizes.
How is the fuse installed in this holder?
The fuse is installed using a clip-in method, allowing for quick and secure installation and replacement.
Common Search Terms
Class J fuse holder, 60A fuse holder, 600V fuse holder, pressure plate fuse holder, IP65 fuse holder, 2-pole fuse holder, industrial fuse holder, DIN rail fuse holder, UltraSafe fuse holder
| Manufacturer Part Number | US6J2 |
|---|---|
| Packed Quantity | 3 |
| Barcode | 0782001830878 |
| Height | 121.9mm |
| Width | 80mm |
| Depth | 88.9mm |
| HS Code | 85369095 |
| Country of Manufacture | China |
| Manufacturer | Mersen |
