MERSEN FUSE 6,9 GS 1 PV 100 V322363
MPN: V322363
Alt. SKU: NH1GS69V100PV
Special Price
£52.92
£44.10
Regular Price
£96.22
MERSEN FUSE 6,9 GS 1 PV 100 V322363 is available to buy in increments of 3
Why Choose the Square Body High-Speed Fuse Protistor® NH Size 0 gS 690VAC IEC 700VAC UL 100A With Double Indicator Plain Blades NH1GS69V100PV?
Engineered for high-performance circuit protection, this high-speed Protistor® fuse ensures rapid and reliable interruption of fault currents up to 100A, safeguarding sensitive equipment in demanding industrial and power electronics applications. Certified to IEC and UL standards for voltages up to 700VAC, it guarantees consistent safety and compliance globally.
Designed with clear double indicators and robust plain blades, the Square Body NH Size 0 format streamlines installation and maintenance while enabling quick visual status checks. Ideal for systems requiring high-speed response and enhanced operational efficiency.
Technical Specifications
- Item number: V322363
- Catalogue No: NH1GS69V100PV
- Description: Square Body High-Speed Fuse Protistor® NH Size 0 gS 690VAC IEC 700VAC UL 100A With Double indicator Plain Blades
- EAN/UPC Code: 3605340360172
- Rated voltage AC UL: 700 V
- Rated voltage AC IEC: 690 V
- Ampere Rating: 100 A
- RoHS Compliant: Yes
- AC or DC: AC
- Speed/Characteristic: gS
- Fuse Size: NH0
- Mounting: Clip
- Clearing I2t At Rated Voltage: 4820 A²s
- Melting I2t: 965 A²s
- AC Max I.R./Breaking Capacity: I1: 160 kA
- Indication System: Yes
- Indication System Type: Double indicator
- Connection/Terminal Material: Brass
- Connection/Terminal Type: Plain Blades
- Product Width: 40 mm
- Product Length: 135 mm
- Product Height: 64 mm
- Sell Pack Quantity: 3 EA
- Sell Pack Weight: 1.2999 kg
- Sell Pack Width: 125 mm
- Sell Pack Length: 140 mm
- Sell Pack Height: 70 mm
- Product group: Semiconductor Protection Fuses
- Body/Insulating Material: Ceramic
- Product Weight: 0.4333 kg
- Power Dissipation at Rated Current Value: 19 W
Product Code: NH1GS69V100PV
Key Benefits
- High-speed interruption for sensitive and demanding applications
- Double indicator system for clear visual status of fuse condition
- Robust ceramic body ensures durability and reliable insulation
- Plain blade terminals allow for easy and secure mounting
- Certified to IEC and UL standards ensuring global compliance
- High breaking capacity of 160 kA for maximum protection
Compatibility
This fuse is compatible with NH Size 0 fuse holders and clips designed for gS characteristic fuses. It is suitable for use in industrial electrical panels, power electronics systems, and semiconductor protection circuits requiring AC voltage ratings up to 700 V.
Applications
- Protection of power semiconductors and converters
- Industrial motor drives and variable speed drives
- High-speed circuit protection in power electronics
- Electrical distribution systems in industrial environments
- Renewable energy systems including solar and wind inverters
Frequently Asked Questions
What does the 'gS' characteristic mean for this fuse?
The 'gS' characteristic indicates a high-speed fuse designed for semiconductor protection, capable of interrupting short-circuit currents quickly to protect sensitive electronic components.
Is this fuse suitable for DC applications?
No, this particular fuse is rated for AC applications only, as specified in the technical specifications.
How does the double indicator system work?
The double indicator system provides a clear visual signal when the fuse has blown, allowing for quick identification and replacement without the need for additional testing equipment.
Can this fuse be used in systems above 700 V AC?
No, this fuse is rated for a maximum AC voltage of 700 V according to UL standards and 690 V according to IEC standards, and should not be used beyond these limits.
Common Search Terms
High-speed fuse, Protistor fuse, NH size 0 fuse, semiconductor protection fuse, 100A fuse, 690VAC fuse, 700VAC fuse, double indicator fuse, ceramic fuse, industrial fuse, power electronics fuse
| Manufacturer Part Number | V322363 |
|---|---|
| Packed Quantity | 3 |
| Barcode | 3605340360172 |
| Height | 135mm |
| Width | 40mm |
| Depth | 64mm |
| HS Code | 85361090 |
| Country of Manufacture | Tunisia |
| Manufacturer | Mersen |
| Alternative Product SKU | NH1GS69V100PV |
