MERSEN FUSE 500V CP 14X51 GG 32A S/I FR14GG50V32
MPN: W216656
Alt. SKU: FR14GG50V32
Special Price
£1.17
£0.9790
Regular Price
£2.14
MERSEN FUSE 500V CP 14X51 GG 32A S/I FR14GG50V32 is available to buy in increments of 10
Why Choose the Cylindrical Fuse-Link gG Size 14x51 IEC 500VAC 32A With Striker FR14GG50V32P?
Engineered for robust circuit protection, this 14x51mm cylindrical fuse-link is rated for up to 500VAC and 32A, fully compliant with IEC standards for reliable operation in industrial low voltage applications. The integrated striker offers instant visual and mechanical indicator functionality, streamlining fuse status monitoring and facilitating remote signalling.
Ideal for safeguarding distribution boards, control gear, and power circuits, the FR14GG50V32P ensures safe disconnection under fault conditions and minimises system downtime. Its compact form factor simplifies installation into new or existing fuse holders, providing dependable protection you can trust.
Product Code: FR14GG50V32P
Key Benefits
- High breaking capacity of 120 kA AC and 100 kA DC ensures reliable fault interruption.
- Integrated striker provides clear visual and mechanical indication of fuse status.
- Compact 14x51mm size fits standard fuse holders for easy installation and replacement.
- Silver-plated copper terminals enhance conductivity and reduce contact resistance.
- Ceramic body offers excellent insulation and thermal stability under load.
- Complies with IEC standards for global industrial applications.
Compatibility
This fuse-link is compatible with IEC standard fuse holders designed for 14x51mm cylindrical fuses, suitable for both AC and DC circuits up to 500 V and 250 V respectively. It is ideal for integration into distribution boards, control panels, and industrial machinery requiring gG type general purpose protection.
Applications
- Industrial low voltage power distribution systems
- Control gear protection in manufacturing plants
- Protection of motor circuits and transformers
- Renewable energy installations such as solar inverters
- Electrical panels in commercial and industrial buildings
Technical Specifications
- Item number: P200757
- Catalogue No: FR14GG50V32P
- Description: Cylindrical fuse-link gG Size 14x51 IEC 500VAC 32A With Striker
- EAN/UPC Code: 8430399008608
- Rated voltage AC IEC: 500 V
- Rated voltage DC IEC: 250 V
- Ampere Rating: 32 A
- AC or DC: AC/DC
- Speed/Characteristic: gG
- Fuse Size: 14x51
- Mounting: Clip
- AC Max I.R./Breaking Capacity: I1: 120 kA
- Max. Rated Breaking Capacity DC: 100 kA @ 250 V, L/R = 15 ms
- Indication System: Yes
- Indication System Type: Striker
- Connection/Terminal Material: Silver-Plated Copper
- Connection/Terminal Type: Ferrule
- Product Diameter: 14.3 mm
- Product Length: 51 mm
- Sell Pack Quantity: 10 EA
- Sell Pack Weight: 0.21 kg
- Sell Pack Width: 75 mm
- Sell Pack Length: 104 mm
- Sell Pack Height: 16 mm
- Product group: Low Voltage IEC Fuses
- Body/Insulating Material: Ceramic
- Product Weight: 0.021 kg
- Power Dissipation at Rated Current Value: 3.6 W
Frequently Asked Questions
What does the 'gG' characteristic mean?
The 'gG' characteristic indicates a general purpose fuse that provides full range protection against overloads and short circuits in industrial applications.
Can this fuse be used in DC circuits?
Yes, the FR14GG50V32P fuse is rated for use in DC circuits up to 250 V with a breaking capacity of 100 kA at L/R = 15 ms.
What is the purpose of the striker indication system?
The striker provides a clear mechanical and visual indication when the fuse has blown, facilitating quick identification and replacement.
Is this fuse compatible with standard 14x51 fuse holders?
Yes, it is designed to fit standard 14x51mm fuse holders with clip mounting.
Common Search Terms
14x51 fuse, cylindrical fuse-link, 32 amp fuse, IEC fuse 500V, gG fuse with striker, industrial fuse 14x51mm, low voltage fuse, fuse-link with indicator, high breaking capacity fuse, ceramic body fuse
| Manufacturer Part Number | W216656 |
|---|---|
| Packed Quantity | 10 |
| Barcode | 8430399008349 |
| Height | 51mm |
| Width | 14.3mm |
| Depth | 14.3mm |
| HS Code | 85361050 |
| Country of Manufacture | Tunisia |
| Manufacturer | Mersen |
| Alternative Product SKU | FR14GG50V32 |
