MERSEN FUSE 500V CP 10X38 GG 8A S/I D217169
MPN: D217169
Alt. SKU: FR10GG50V8
Special Price
£0.6732
£0.5610
Regular Price
£1.22
MERSEN FUSE 500V CP 10X38 GG 8A S/I D217169 is available to buy in increments of 10
Why Choose the Cylindrical Fuse-Link gG Size 10x38 IEC 500VAC 8A FR10GG50V8?
The FR10GG50V8 fuse-link offers reliable circuit protection for general industrial applications, conforming to IEC standards and rated up to 500VAC at 8A. Its compact 10x38mm cylindrical design ensures compatibility with standard fuse holders and panels.
Engineered for consistent performance, rapid fault interruption, and easy installation, this gG type fuse-link minimises downtime and enhances safety in control panels, motor circuits, and power distribution systems.
Product Code: FR10GG50V8
Key Benefits
- Reliable circuit protection with high breaking capacity (120 kA AC, 100 kA DC)
- Compact 10x38 mm size fits standard fuse holders and panels
- Ceramic body ensures durability and high temperature resistance
- Silver-plated copper terminals for excellent conductivity and corrosion resistance
- gG characteristic provides full range protection for cables and equipment
- Easy installation with clip mounting
- Conforms to IEC standards for safety and performance
Compatibility
This fuse-link is compatible with IEC standard fuse holders designed for 10x38 mm fuses. It is suitable for use in low voltage industrial control panels, motor protection circuits, and power distribution systems requiring 500 V AC or 250 V DC rated fuses with an 8A rating.
Applications
- Industrial control panels
- Motor protection circuits
- Power distribution boards
- General electrical equipment protection
- Renewable energy systems
- Automation and machinery safety circuits
Technical Specifications
- Item number: D217169
- Catalogue No: FR10GG50V8
- Description: Cylindrical fuse-link gG Size 10x38 IEC 500VAC 8A
- EAN/UPC Code: 8430399007731
- Rated voltage AC IEC: 500 V
- Rated voltage DC IEC: 250 V
- Ampere Rating: 8 A
- AC or DC: AC/DC
- Speed/Characteristic: gG
- Fuse Size: 10x38
- Mounting: Clip
- AC Max I.R./Breaking Capacity: I1: 120 kA
- Max. Rated Breaking Capacity DC: 100 kA @ 250 V, L/R = 15 ms
- Connection/Terminal Material: Silver-Plated Copper
- Connection/Terminal Type: Ferrule
- Product Diameter: 10.3 mm
- Product Length: 38 mm
- Sell Pack Quantity: 10 EA
- Sell Pack Weight: 0.083 kg
- Sell Pack Width: 55 mm
- Sell Pack Length: 81 mm
- Sell Pack Height: 14 mm
- Product group: Low Voltage IEC Fuses
- Body/Insulating Material: Ceramic
- Product Weight: 0.0083 kg
- Power Dissipation at Rated Current Value: 1.15 W
Frequently Asked Questions
What does the gG characteristic mean?
The gG characteristic indicates a general purpose fuse suitable for protection of cables and electrical equipment against overload and short-circuit currents.
Can this fuse be used in DC circuits?
Yes, this fuse is rated for both AC (500 V) and DC (250 V) applications, making it suitable for a variety of industrial circuits.
What is the breaking capacity of this fuse?
The fuse has a maximum breaking capacity of 120 kA at AC and 100 kA at DC (250 V, L/R = 15 ms), ensuring it can safely interrupt high fault currents.
Is the fuse body material suitable for high temperatures?
Yes, the fuse body is made of ceramic, which provides excellent heat resistance and durability under high temperature conditions.
How is this fuse mounted?
The fuse is designed for clip mounting, compatible with standard 10x38 mm fuse holders.
Common Search Terms
10x38 fuse, cylindrical fuse-link, gG fuse 8A, IEC fuse 500VAC, industrial fuse-link, motor protection fuse, ceramic fuse 10x38, high breaking capacity fuse, clip mount fuse, general purpose fuse-link
| Manufacturer Part Number | D217169 |
|---|---|
| Packed Quantity | 10 |
| Barcode | 8430399007731 |
| Height | 38mm |
| Width | 10.3mm |
| Depth | 10.3mm |
| HS Code | 85361010 |
| Manufacturer | Mersen |
| Alternative Product SKU | FR10GG50V8 |
