01013000A Woehner 3 pole 500A Connection Terminal Plate
MPN: 01013
Alt. SKU: 01013000A
Special Price
£92.42
£77.02
Regular Price
£115.54
Why Choose the Wöhner 01013 Connection Terminal Plate?
The Wöhner 01013 is a heavy-duty 3-pole connection terminal plate engineered for secure high-current termination on CrossBoard® 800 A busbar systems. Designed for industrial distribution boards and OEM panel builds, it provides a reliable interface for large feeder cables while maintaining structured, space-efficient busbar layouts.
Supporting conductor sizes from 95 to 300 mm², the 01013 uses captive clamping screws to ensure consistent tightening and secure cable retention. Clear torque and cross-section markings on each terminal support compliant installation and reduce wiring errors in high-current feeder assemblies.
Key Features
- Connection range: 95 to 300 mm² for high-current feeder applications.
- 3-pole configuration for balanced power distribution.
- Captive screw terminals for secure and reliable clamping.
- Conductor overlap permitted for flexible cable routing.
- Terminal markings indicate nominal cross-section and tightening torque.
- Designed specifically for CrossBoard® 800 A systems.
- Robust construction suitable for industrial distribution environments.
Technical Specifications
- Manufacturer: Wöhner
- Model: 01013
- MPN: 01013000A
- Product type: 3-pole connection terminal plate
- System compatibility: CrossBoard® 800 A
- Connection range: 95 to 300 mm²
- Poles: 3
- Terminal type: Captive screw clamping
- Conductor overlap: Permitted
- Markings: Nominal cross-section and tightening torque indicated
- Material: Halogen-free
- EAN: 4021267010133
Typical Applications
- High-current feeder termination on CrossBoard® 800 A busbar systems.
- Industrial 400 V distribution boards and switchgear assemblies.
- OEM machine control panels requiring structured large-conductor terminations.
- Applications where conductor overlap simplifies cable routing.
Frequently Asked Questions
What conductor sizes can the Wöhner 01013 accept?
The 01013 supports copper conductors from 95 mm² to 300 mm², making it suitable for high-current feeder connections.
Is this terminal plate compatible with CrossBoard® 800 A systems?
Yes. The 01013 is specifically designed for integration with CrossBoard® 800 A busbar systems.
What type of connection technology does it use?
It uses captive clamping screws to ensure secure conductor retention and consistent tightening during installation.
Can conductors be overlapped?
Yes. Conductor overlap is permitted, allowing flexible cable entry and routing options within distribution panels.
Where can I find installation documentation?
Technical documentation and installation instructions are available from the manufacturer’s official product resources.
| Manufacturer Part Number | 01013 |
|---|---|
| Barcode | 4021267010133 |
| Height | 208mm |
| Width | 208mm |
| Depth | 153mm |
| Country of Manufacture | Germany |
| HS Code | 85369010 |
| Alternative Product SKU | 01013000A |
| Manufacturer | Wohner |
| Packed Quantity | 1 |
| Range | Crossboard |
| Number of Poles | 3 pole |
| Halogen free | Yes |
| Rated voltage | 690V |
| Rated current | 500A |
| Max. conductor cross section | 300 |
| Width clamp | 170.5mm |
| Max. rated operation current Ie | 500A |
| Rated voltage AC | 600V |
| Rated surge voltage | 6kV |
| Rated Frequency | 50/60Hz |
| Rated Isolation Voltage Ui AC | 1000V |
| Max. peak current | 80kA |
| Rated short-time withstand current lcw | 30kA |
| max. permitted voltage (IEC) DC | 1000V |
| Max. Permitted Voltage (IEC) AC | 1000V |
| SCCR | 65 kA with any DIVQ/7 circuit breaker 800 A / 480 V AC |
| Min. Cross Section | 95 mm² |
| Max. Cross Section | 300 mm² |
| Suitable Conductor Connection | Round Conductor, Sector Conductor |
