GE0251T4 - 4P SWITCH DISCONNECTOR

Why Choose the GE0251T4?

Lovato GE0251T4 is a four-pole switch disconnector for dependable AC isolation in industrial panels. Rated Ith 250 A with Ui 1000 V and Uimp 8 kV, it supports AC-21A/AC-22A/AC-23A duties up to 690 V. Screw-on plate mounting and IP20 frontal protection simplify integration while helping safeguard operators. Part of the GE series, it delivers reliable load breaking and isolation where robust performance and compliance are essential.

With a 2.5 W max power dissipation per pole and 20,000 mechanical cycles, GE0251T4 is engineered for efficiency and durability. AC-23A making/breaking at 400 V is 2500 A/2000 A, with a conditional short-circuit current of 100 kA when protected by a gG250 fuse. Operates from -25 to 55 °C, up to 3000 m altitude, torque to 18 Nm, and meets IEC/EN 60947-1 and 60947-3.

Key Benefits

• 4-pole AC isolation with 250 A Ith for heavy-duty circuits.
• Rated insulation Ui 1000 V and 8 kV impulse withstand.
• AC-23A making 2500 A and breaking 2000 A at 400 V.
• High conditional short-circuit current 100 kA with gG250 fuse.
• IP20 frontal protection enhances operator safety during operation.
• Durable 20,000 mechanical cycles for long service life.
• Wide operating range: -25 to 55 °C, up to 3000 m altitude.

Technical Specification

• Product type designation: GE
• Number of poles: 4
• Operating voltage type: AC
• Ith (IEC): 250 A
• Rated insulation voltage Ui (IEC/EN): 1000 V
• Rated impulse withstand voltage Uimp: 8 kV
• Operating current Ie AC21A 400 V: 250 A
• Operating current Ie AC21A 500 V: 250 A
• Operating current Ie AC21A 690 V: 200 A
• Operating current Ie AC22A 400 V: 250 A
• Operating current Ie AC22A 500 V: 250 A
• Operating current Ie AC22A 690 V: 160 A
• Operating current Ie AC23A 400 V: 250 A
• Operating current Ie AC23A 500 V: 200 A
• Operating current Ie AC23A 690 V: 160 A
• Power dissipation per pole (max): 2.5 W
• Rated operational power AC23A 400 V: 138 kW
• Rated operational power AC23A 690 V: 153 kW
• Conditional short-circuit current (rms): 100 kA
• Short-circuit protection fuse: gG250
• Making capacity AC23A 400 V: 2500 A
• Breaking capacity AC23A 400 V: 2000 A
• Mechanical life: 20000 cycles
• Terminal tightening torque (max): 18 Nm
• Operating temperature: -25 to 55 °C
• Storage temperature: -40 to 70 °C
• Max altitude: 3000 m
• IP degree (frontal): IP20
• Pollution degree: 3

What’s Included

• Lovato GE0251T4 switch disconnector
• Installation and safety instructions
• Manufacturer product datasheet

Applications

• Main isolator and load switch in industrial control panels
• Maintenance isolation for machinery and motor circuits (within AC-23A ratings)
• Power distribution switching up to 690 V AC, as specified
• Switchboards and distribution boards requiring 4-pole isolation

Safety note: Installation and maintenance must be performed by qualified personnel with the circuit de-energised. Use the specified gG250 fuse, tighten terminals to 18 Nm, and operate within the stated temperature, altitude and IP20 limitations.
