GE0200 - 3P SWITCH DISCONNECTOR

Why Choose the GE0200?

Lovato’s GE0200 is a compact, three-pole switch disconnector engineered for dependable isolation of AC circuits up to 200 A. With Ui 1000 V, Uimp 8 kV and IP20 frontal protection, it delivers industrial performance and safety. The GE0200 mounts by screw on plate and complies with IEC/EN 60947-1 and 60947-3, supporting robust operation in control panels and distribution assemblies.

High utilisation ratings cover AC21A and AC22A to 200 A, and AC23A to 160 A at 400 V (125 A at 500 V, 80 A at 690 V), with up to 90 kW AC23A at 400 V. A 100 kA conditional short-circuit current with gG200 fuse enhances resilience. Designed for longevity with 30,000 mechanical cycles, it operates from -25 to 55 °C up to 3000 m altitude.

Key Benefits

• Reliable 3-pole isolation for AC circuits up to 200 A.
• High insulation strength: Ui 1000 V and Uimp 8 kV.
• Versatile AC21A, AC22A and AC23A utilisation for switching and isolation.
• Robust short-circuit withstand with 100 kA conditional current rating.
• IP20 frontal protection improves operator safety during panel operation.
• Long mechanical life of 30,000 cycles reduces downtime.
• Screw-on plate installation and 18 Nm terminals for secure connections.
• Wide operating range: -25 to 55 °C and up to 3000 m.

Technical Specification

• Product type designation: GE
• Number of poles: 3
• Operating voltage type: AC
• Ith (IEC): 200 A
• Rated insulation voltage Ui (IEC/EN): 1000 V
• Rated impulse withstand voltage Uimp: 8 kV
• Operating current Ie AC21A 400 V: 200 A
• Operating current Ie AC21A 500 V: 200 A
• Operating current Ie AC21A 690 V: 180 A
• Operating current Ie AC22A 400 V: 200 A
• Operating current Ie AC22A 500 V: 200 A
• Operating current Ie AC22A 690 V: 160 A
• Operating current Ie AC23A 400 V: 160 A
• Operating current Ie AC23A 500 V: 125 A
• Operating current Ie AC23A 690 V: 80 A
• Power dissipation per pole (max): 6 W
• Rated operational power AC23A 400 V: 90 kW
• Rated operational power AC23A 690 V: 75 kW
• Conditional short-circuit current (rms): 100 kA
• Short-circuit protection fuse: gG200
• Making capacity AC23A 400 V: 1600 A
• Breaking capacity AC23A 400 V: 1280 A
• Mechanical life: 30000 cycles
• Terminal tightening torque (max): 18 Nm
• Operating temperature: -25 to 55 °C
• Storage temperature: -40 to 70 °C
• Max altitude: 3000 m
• IP degree (frontal): IP20
• Pollution degree: 3

What’s Included

• Lovato GE0200 3-pole switch disconnector
• Manufacturer documentation
• Compliance and safety information

Applications

• Main isolator for industrial control panels and distribution boards
• Switching and isolation of AC loads in manufacturing environments
• Motor and machinery isolation under AC23A duty
• HVAC, pumps and conveyors requiring dependable disconnection
• On-site maintenance lock-off and safe circuit segregation

Safety note: Install and commission only by qualified personnel. De-energise circuits before work, apply the specified gG200 short-circuit protection, and tighten terminals to 18 Nm. Observe IEC/EN 60947 requirements and environmental limits.
