ABB S203M-B25 MCB - S200M - 3P - B - 25A
MPN: 2CDS273001R0255
Alt. SKU: S203M-B25
Special Price
£60.88
£50.73
Regular Price
£110.68
Why Choose the S203M-B25 [2CDS273001R0255]
System pro M compact S200M miniature circuit breakers are current limiting. They have two different tripping mechanisms, the delayed thermal tripping mechanism for overload protection and the electromechanic tripping mechanism for short circuit protection. They are available in different characteristics (B,C,D,K,Z), configurations (1P,1P+N,2P,3P,3P+N,4P), breaking capacities (up to 10 kA at 230/400 V AC) and rated currents (up to 63A). All MCBs of the product range S200M comply with IEC/EN 60898-1 and IEC/EN 609 47-2, allowing the use for residential, commercial and industrial applications. Bottom-fitting auxiliary contact can be mounted on S200M to save 50% space.
Technical Specification
- Function: Current-limiting miniature circuit breaker with thermal overload and electromechanic short-circuit tripping.
- Voltage & Current Ratings: Up to 400 V AC; rated current 25 A.
- Contact Configuration: 3-pole (3P).
- Breaking Capacity: Ultimate up to 25 kA at 230 V AC, 15 kA at 400/440 V AC; Service short-circuit breaking capacity 7.5 kA at 230 V AC.
- Terminal Type & Size Range: Screw terminals; busbar 10/10 mm², flexible 0.75–25 mm², rigid 0.75–35 mm².
- Mechanical & Electrical Endurance: 20,000 mechanical cycles; 20,000 AC electrical cycles.
- Insulation & Dielectric Test: Rated dielectric withstand voltage 2 kV at 50/60 Hz for 1 minute.
- Contact Position Indication: Red (ON) / Green (OFF).
Trusted By Customers Worldwide
"Specified by UK panel builders for dependable control." Controls Engineer, UK
Frequently Asked Questions
What types of tripping mechanisms are used in the S200M miniature circuit breakers?
The S200M miniature circuit breakers utilise a delayed thermal tripping mechanism for overload protection and an electromechanic tripping mechanism for short circuit protection.
What is the maximum breaking capacity of the S200M circuit breakers?
The S200M circuit breakers have a breaking capacity of up to 10 kA at 230/400 V AC.
What configurations are available for the S200M circuit breakers?
The S200M circuit breakers are available in various configurations including 1P, 1P+N, 2P, 3P, 3P+N, and 4P.
What is the rated current for the S200M circuit breakers?
The rated current for the S200M circuit breakers is up to 63A.
What is the terminal type and size range for the S200M circuit breakers?
The S200M circuit breakers feature screw terminals with a busbar size of 10/10 mm², and flexible and rigid conductor sizes ranging from 0.75–25 mm² and 0.75–35 mm² respectively.
What standards do the S200M circuit breakers comply with?
All MCBs of the S200M product range comply with IEC/EN 60898-1 and IEC/EN 609 47-2. See the manufacturer's data sheet for standards and approvals.
Can auxiliary contacts be mounted on the S200M circuit breakers?
Yes, a bottom-fitting auxiliary contact can be mounted on the S200M to save 50% space.
| Manufacturer Part Number | 2CDS273001R0255 |
|---|---|
| Amperage | 25A |
| Number of Poles | 3 Pole |
| Trip Curve Type | Type B 10KA |
| HS Code | 85362010 |
| Country of Manufacture | Germany |
| Manufacturer | ABB |
| Alternative Product SKU | S203M-B25 |
| Barcode | 4016779549714 |
