ABB S201M-B40 MCB - S200M - 1P - B - 40A
MPN: 2CDS271001R0405
Alt. SKU: S201M-B40
Special Price
£15.13
£12.61
Regular Price
£27.52
Why Choose the S201M-B40 [2CDS271001R0405]
System pro M compact S200M miniature circuit breakers are current limiting. They have two different tripping mechanisms, the delayed thermal tripping mechanism for overload protection and the electromechanic tripping mechanism for short circuit protection. They are available in different characteristics (B,C,D,K,Z), configurations (1P,1P+N,2P,3P,3P+N,4P), breaking capacities (up to 10 kA at 230/400 V AC) and rated currents (up to 63A). All MCBs of the product range S200M comply with IEC/EN 60898-1 and IEC/EN 609 47-2, allowing the use for residential, commercial and industrial applications. Bottom-fitting auxiliary contact can be mounted on S200M to save 50% space.
Technical Specification
- Function: Miniature circuit breaker with thermal and electromechanical tripping for overload and short circuit protection.
- Voltage Rating: Up to 400 V AC, 60 V DC maximum operating voltage.
- Current Rating: Up to 63 A rated current; this model S201M-B40 is rated 40 A.
- Contact Configuration: Single pole (1P) with red ON/green OFF indication.
- Breaking Capacity: Up to 25 kA at 133 V AC, 15 kA at 230/400 V AC.
- Terminal Type and Size Range: Screw terminals; compatible with flexible cables 0.75 to 25 mm², rigid cables 0.75 to 35 mm², and busbars 10/10 mm².
- Durability: Mechanical endurance of 20,000 cycles; electrical endurance of 10,000 to 20,000 AC cycles.
- Standards Compliance: IEC/EN 60898-1, IEC/EN 60947-2.
Trusted By Customers Worldwide
"Specified by UK panel builders for dependable control." Controls Engineer, UK
Frequently Asked Questions
What is the function of the S200M miniature circuit breakers?
The S200M miniature circuit breakers provide overload and short circuit protection through thermal and electromechanical tripping mechanisms.
What are the available configurations for the S200M circuit breakers?
The S200M circuit breakers are available in configurations of 1P, 1P+N, 2P, 3P, 3P+N, and 4P.
What is the maximum breaking capacity of the S200M circuit breakers?
The maximum breaking capacity is up to 25 kA at 133 V AC and 15 kA at 230/400 V AC.
What is the rated current for the S201M-B40 model?
The S201M-B40 model is rated for 40 A.
What cable sizes are compatible with the S200M circuit breakers?
The S200M circuit breakers are compatible with flexible cables from 0.75 to 25 mm², rigid cables from 0.75 to 35 mm², and busbars of 10/10 mm².
How durable are the S200M circuit breakers?
The mechanical endurance is rated at 20,000 cycles, while the electrical endurance ranges from 10,000 to 20,000 AC cycles.
What standards do the S200M circuit breakers comply with?
All S200M circuit breakers comply with IEC/EN 60898-1 and IEC/EN 60947-2. See the manufacturer's data sheet for standards and approvals.
| Manufacturer Part Number | 2CDS271001R0405 |
|---|---|
| Amperage | 40A |
| Number of Poles | 1 Pole |
| Trip Curve Type | Type B 10KA |
| HS Code | 85362010 |
| Country of Manufacture | Germany |
| Manufacturer | ABB |
| Alternative Product SKU | S201M-B40 |
| Barcode | 4016779549493 |
