ABB CR-P048DC2 Pack of 10 Pluggable Relays 2C/O 48VDC
MPN: 1SVR405601R6000
Alt. SKU: CR-P048DC2
Special Price
£35.03
£29.19
Regular Price
£53.88
Why Choose the CR-P048DC2 [1SVR405601R6000]
The CR-P048DC2 pluggable interface relay is suitable for direct mounting on a printed circuit board or use in conjunction with ABB's sockets. This relay operates with a 48 V DC rated control supply voltage and has a 2 c/o (SPDT) output with contacts rated at 250 V / 8 A, enabling the possibility of switching multiple circuits with a single input signal. Coupled with a socket, the compact size of this relay offers possibilities to save space within a control panel. Furthermore, with an IP degree of 67, this relay offers complete protection against ingress of dust and airborne particles & protection against water and liquids, up to and including immersion in up to one meter of water. Standard sockets, logical sockets, pluggable function modules, holder and marker are available as accessories.
Technical Specification
- Function: Pluggable PCB interface relay, 2 C/O (SPDT) output contacts.
- Rated Control Supply Voltage: 48 V DC.
- Contact Rating: 250 V / 8 A.
- Rated Operational Voltage: 400 V AC, 50/60 Hz.
- Rated Operational Current: AC-12: 8 A at 230 V; AC-15: 3 A at 120 V, 1.5 A at 230 V; DC-12: 8 A at 24 V; DC-13: 2 A at 24 V, 0.1 A at 250 V.
- Terminal Type: Soldering pins.
- Degree of Protection: IP67 (dust tight and protected against immersion up to 1 metre).
- Rated Insulation Voltage: 400 V.
- Standards Compliance: IEC/EN 61810-1, UL94 V-0 flammability rating.
Trusted By Customers Worldwide
"Specified by UK panel builders for dependable control." Controls Engineer, UK
Frequently Asked Questions
What is the rated control supply voltage for the CR-P048DC2 relay?
The rated control supply voltage for the CR-P048DC2 relay is 48 V DC.
What is the contact rating of the relay?
The contact rating is 250 V / 8 A.
Can the CR-P048DC2 relay be mounted directly on a PCB?
Yes, the CR-P048DC2 relay is suitable for direct mounting on a printed circuit board.
What is the degree of protection for this relay?
The relay has an IP67 rating, providing complete protection against dust and immersion in water up to one metre.
What types of sockets are compatible with the CR-P048DC2 relay?
The relay can be used in conjunction with standard sockets and logical sockets, which are available as accessories.
What are the rated operational voltages for the relay?
The rated operational voltage is 400 V AC, 50/60 Hz.
What standards does the CR-P048DC2 relay comply with?
See the manufacturer's data sheet for standards and approvals.
| Manufacturer Part Number | 1SVR405601R6000 |
|---|---|
| Manufacturer | ABB |
| Packed Quantity | 10 |
| HS Code | 85364900 |
| Amperage | 8A |
| Number of Poles | 2 Pole |
| Barcode | 4013614498282 |
| Country of Manufacture | Poland |
| Alternative Product SKU | CR-P048DC2 |
| Coil Voltage | 48V DC |
