1SFL587002R1311 af305-30-11-13 160kw/305 amp 100-250v 50/60hz-dc ABB Contactor
MPN: 1SFL587002R1311
Alt. SKU: AF305-30-11-13
Special Price
£1,112.33
£926.94
Regular Price
£1,711.27
Why Choose the AF305-30-11-13 [1SFL587002R1311]
The AF305-30-11-13 is a 3 pole - 1000 V IEC or 600 V UL contactor with pre-mounted auxiliary contacts and Main Circuit Bars, controlling motors up to 160 kW / 400 V AC (AC-3) or 250 hp / 480 V UL and switching power circuits up to 500 A (AC-1) or 400 A UL general use. Thanks to the AF technology, the contactor has a wide control voltage range (100-250 V 50/60 Hz and DC), managing large control voltage variations, reducing panel energy consumptions and ensuring distinct operations in unstable networks. Furthermore, surge protection is built-in, offering a compact solution. AF contactors have a block type design, can be easily extended with add-on auxiliary contact blocks and an additional wide range of accessories. Includes Mounting kit, containing all neccessary screws, washers and sockets for connecting the terminals, and screws for mounting the device.
Technical Specification
- Function: 3-pole contactor for motor control and power switching up to 500 A (AC-1) / 400 A UL general use.
- Voltage Ratings: Main circuit up to 1000 V IEC / 600 V UL; control circuit 100-250 V AC/DC.
- Current Ratings: Rated operational currents up to 305 A AC-3 (motor control) and 500 A DC-1.
- Contact Configuration: 3 main contacts NO; auxiliary contacts 1 NO + 1 NC pre-mounted.
- Insulation & Impulse Voltage: Rated insulation voltage 1000 V; impulse withstand voltage 8 kV.
- Protection Rating: Coil terminals IP20; main terminals IP00 (per IEC 60529).
- Terminal Type & Size: Main circuit bars; flexible cable up to 240 mm²; rigid aluminium up to 240 mm²; rigid copper up to 185 mm².
- Mechanical Durability: 5 million operating cycles.
- Mounting: Includes full mounting kit with screws, washers and sockets.
Trusted By Customers Worldwide
"Specified by UK panel builders for dependable control." Controls Engineer, UK
Frequently Asked Questions
What is the maximum motor control capacity of the AF305-30-11-13 contactor?
The AF305-30-11-13 contactor can control motors up to 160 kW at 400 V AC (AC-3) or 250 hp at 480 V UL.
What is the maximum switching power circuit capacity?
This contactor can switch power circuits up to 500 A (AC-1) or 400 A UL general use.
What is the control voltage range for this contactor?
The control voltage range is 100-250 V at 50/60 Hz and DC.
What type of mounting kit is included with the contactor?
The mounting kit includes all necessary screws, washers, and sockets for connecting terminals, as well as screws for mounting the device.
What is the protection rating of the AF305-30-11-13 contactor?
The coil terminals have an IP20 rating, while the main terminals have an IP00 rating, according to IEC 60529.
What is the mechanical durability of this contactor?
The AF305-30-11-13 contactor has a mechanical durability of 5 million operating cycles.
What are the terminal types and sizes compatible with this contactor?
The contactor supports flexible cables up to 240 mm², rigid aluminium up to 240 mm², and rigid copper up to 185 mm².
| Manufacturer Part Number | 1SFL587002R1311 |
|---|---|
| Manufacturer | ABB |
| Alternative Product SKU | AF305-30-11-13 |
| KW Rating | 160kW |
| Inbuilt Aux | 1 N/O 1 N/C |
| Barcode | 7320500481776 |
| Product Lead Time | Please contact us for a delivery time |
Write Your Own Review
ABB AF Contactor RangeABB contactor range can be used to control power circuits up to a level of 690 V AC and 220 V DC. The main benefit of ABB's range of AF products are that only a few coils are needed for different control voltages used in many applications without having to change the coil. |
