1SFL487002R1311 af190-30-11-13 90kw/190 amp 100-250v 50/60hz-dc ABB Contactor
MPN: 1SFL487002R1311
Alt. SKU: AF190-30-11-13
Special Price
£556.24
£463.53
Regular Price
£855.74
Why Choose the AF190-30-11-13 [1SFL487002R1311]
The AF190-30-11-13 is a 3 pole - 1000 V IEC or 600 V UL contactor with pre-mounted auxiliary contacts and Main Circuit Bars, controlling motors up to 90 kW / 400 V AC (AC-3) or 125 hp / 480 V UL and switching power circuits up to 275 A (AC-1) or 250 A UL general use. Thanks to the AF technology, the contactor has a wide control voltage range (100-250 V 50/60 Hz and DC), managing large control voltage variations, reducing panel energy consumptions and ensuring distinct operations in unstable networks. Furthermore, surge protection is built-in, offering a compact solution. AF contactors have a block type design, can be easily extended with add-on auxiliary contact blocks and an additional wide range of accessories. Includes Mounting kit, containing all neccessary screws, washers and sockets for connecting the terminals, and screws for mounting the device.
Technical Specification
- Function: 3 pole contactor for motor control up to 90 kW / 400 V AC (AC-3) and switching power circuits up to 275 A (AC-1).
- Rated Operational Voltage: Main circuit up to 1000 V IEC / 600 V UL.
- Rated Operational Current: 275 A (AC-1) at 690 V, 190 A (AC-3) at 415 V.
- Contact Configuration: 3 main NO contacts, 1 auxiliary NO, 1 auxiliary NC contact pre-mounted.
- Insulation & Impulse Ratings: Rated insulation voltage 1000 V; impulse withstand voltage 8 kV.
- Degree of Protection: Coil terminals IP20, main terminals IP00.
- Terminal Type & Size Range: Main circuit bars; flexible 2x50–95 mm², rigid Al 1x95–185 mm², rigid Cu 1x6–150 mm².
- Mechanical Durability: 5 million operations.
- Coil Control Voltage Range: 100–250 V AC/DC, wide tolerance for unstable networks.
Trusted By Customers Worldwide
"Specified by UK panel builders for dependable control." Controls Engineer, UK
Frequently Asked Questions
What is the maximum motor control capacity of the AF190-30-11-13 contactor?
The AF190-30-11-13 contactor can control motors up to 90 kW at 400 V AC (AC-3).
What is the rated operational current for power circuits?
The rated operational current for power circuits is 275 A (AC-1).
What is the degree of protection for the terminals?
The coil terminals have an IP20 rating, while the main terminals have an IP00 rating.
What type of terminals does the AF190-30-11-13 use?
The contactor uses main circuit bars with flexible and rigid terminal options for various cable sizes.
Can the AF190-30-11-13 contactor be extended with additional components?
Yes, it can be easily extended with add-on auxiliary contact blocks and a wide range of accessories.
What is the coil control voltage range for the contactor?
The coil control voltage range is 100–250 V AC/DC.
What standards and approvals does the AF190-30-11-13 conform to?
See the manufacturer's data sheet for standards and approvals.
| Manufacturer Part Number | 1SFL487002R1311 |
|---|---|
| Manufacturer | ABB |
| Alternative Product SKU | AF190-30-11-13 |
| KW Rating | 90kW |
| Inbuilt Aux | 1 N/O 1 N/C |
| Barcode | 7320500480434 |
| Product Lead Time | Please contact us for a delivery time |
Write Your Own Review
ABB AF Contactor RangeABB contactor range can be used to control power circuits up to a level of 690 V AC and 220 V DC. The main benefit of ABB's range of AF products are that only a few coils are needed for different control voltages used in many applications without having to change the coil. |
