M1P00912400A6 - DOL STARTER M1P 400/50-60 1.6-2.5A
MPN: M1P00912400A6
Special Price
£157.50
£131.25
Regular Price
£262.49
Why Choose the M1P00912400A6?
The Lovato Direct-on-line-starter M1P00912400A6 provides dependable control for small motors. It covers 1.6–2.5 A with 0.75 kW at 400 V (AC3), combining a 400 VAC 50/60 Hz coil contactor and thermal overload relay in a rugged, non‑metallic IP65 enclosure. Clearly labelled START and STOP/RESET pushbuttons support straightforward commissioning, operation and routine resets.
Designed for harsh industrial environments, this Direct-on-line-starter meets IEC/EN 60947-1 and 60947-4-1, and is recognised under UL508 and CSA C22.2 n° 14. The IP65 non‑metallic enclosure resists dust and jets of water, while the wide -25 to +60 °C operating range enhances reliability. A 1 HP rating at 480 V supports international applications and panel standardisation.
Key Benefits
- IP65 non‑metallic enclosure for dust-tight, water‑jet resistant protection.
- Integrated thermal overload relay safeguards motors within 1.6–2.5 A.
- 0.75 kW at 400 V AC3 rating suits small three‑phase motors.
- Simple START and STOP/RESET buttons aid safe local control.
- 400 VAC 50/60 Hz AC coil compatible with common supplies.
- Certified to IEC/EN 60947 and UL/CSA standards for compliance.
- Wide -25 to +60 °C operating temperature supports harsh sites.
Technical Specification
- Weight: 1040 g
- Operating temperature: -25 to +60 °C
- Storage temperature: -40 to +70 °C
What’s Included
- Enclosed direct-on-line starter with integrated thermal overload relay
- Non‑metallic IP65 enclosure with START and STOP/RESET pushbuttons
- 400VAC 50/60Hz AC coil contactor, preassembled in enclosure
- Product documentation and datasheet (downloadable)
Applications
- Controlling small three‑phase motors up to 0.75 kW at 400 V
- Pumps, fans and blowers in industrial and commercial sites
- Conveyors, packaging and light material handling equipment
- Machine auxiliaries and general automation panels
- HVAC and building services plant rooms
Frequently Asked Questions
What is the motor rating at 400 V?
It is rated 0.75 kW (AC3) at 400 V with a 2.5 A Ie.
What overload range does the relay cover?
The thermal overload relay setting range is 1.6 to 2.5 A.
What is the coil supply required?
The contactor coil is 400 VAC, suitable for 50/60 Hz supplies.
Is the enclosure suitable for harsh environments?
Yes, the non‑metallic enclosure is rated IP65 for dust and water‑jet protection.
Which standards does it meet?
It conforms to IEC/EN 60947-1 and 60947-4-1 and is recognised under UL508 and CSA C22.2 n° 14.
Safety note: Installation and adjustments must be carried out by qualified personnel. Isolate power before work, set the thermal overload to the motor’s rated current, and follow applicable standards.
| Manufacturer Part Number | M1P00912400A6 |
|---|---|
| Manufacturer | Lovato |
| HS Code | 85371098 |
| Barcode | 8013975149744 |
