ABB CR-P048AC2 Pack of 10 Pluggable Relays 2C/O 48VAC
MPN: 1SVR405601R5000
Alt. SKU: CR-P048AC2
Special Price
£41.42
£34.52
Regular Price
£63.72
Why Choose the CR-P048AC2 [1SVR405601R5000]
The CR-P048AC2 pluggable interface relay is suitable for direct mounting on a printed circuit board or use in conjunction with ABB's sockets. This relay operates with a 48 V AC rated control supply voltage and has a 2 c/o (SPDT) output with contacts rated at 250 V / 8 A, enabling the possibility of switching multiple circuits with a single input signal. Coupled with a socket, the compact size of this relay offers possibilities to save space within a control panel. Furthermore, with an IP degree of 67, this relay offers complete protection against ingress of dust and airborne particles & protection against water and liquids, up to and including immersion in up to one meter of water. Standard sockets, logical sockets, pluggable function modules, holder and marker are available as accessories.
Technical Specification
- Function: Pluggable PCB interface relay with 2 C/O (SPDT) contacts.
- Control Supply Voltage: 48 V AC rated.
- Output Ratings: 250 V / 8 A switching capacity.
- Operational Current: AC-12: 8 A at 230 V; AC-15: 3 A at 120 V, 1.5 A at 230 V; DC-12: 8 A at 24 V; DC-13: 2 A at 24 V, 0.1 A at 250 V.
- Insulation Voltage: Rated at 400 V.
- Degree of Protection: IP67, dust tight and water immersion resistant to 1 m.
- Terminal Type: Soldering pins for PCB mounting.
- Standards Compliance: IEC/EN 61810-1, UL94 V-0 flammability rating.
Trusted By Customers Worldwide
"Specified by UK panel builders for dependable control." Controls Engineer, UK
Frequently Asked Questions
What is the rated control supply voltage for the CR-P048AC2 relay?
The rated control supply voltage for the CR-P048AC2 relay is 48 V AC.
What are the output ratings of the relay?
The relay has output contacts rated at 250 V / 8 A.
Can the CR-P048AC2 relay be mounted directly on a PCB?
Yes, the CR-P048AC2 relay is suitable for direct mounting on a printed circuit board.
What is the degree of protection for the CR-P048AC2 relay?
The relay has an IP67 rating, providing complete protection against dust and immersion in water up to one metre.
What types of sockets are compatible with the CR-P048AC2 relay?
The relay can be used in conjunction with standard sockets and logical sockets, which are available as accessories.
What are the operational current ratings for AC and DC?
For AC-12, the operational current is 8 A at 230 V; for AC-15, it is 3 A at 120 V and 1.5 A at 230 V; for DC-12, it is 8 A at 24 V and for DC-13, it is 2 A at 24 V and 0.1 A at 250 V.
What standards does the CR-P048AC2 relay comply with?
See the manufacturer's data sheet for standards and approvals.
| Manufacturer Part Number | 1SVR405601R5000 |
|---|---|
| Manufacturer | ABB |
| Packed Quantity | 10 |
| Amperage | 8A |
| Number of Poles | 2 Pole |
| Product Lead Time | Please contact us for a delivery time |
| Barcode | 4013614498275 |
| Alternative Product SKU | CR-P048AC2 |
| Coil Voltage | 48VAC |
