11BG0040A110 - CONTROL RELAY BG00.40A 110V 50-60HZ
MPN: 11BG0040A110
Alt. SKU: BG0040A110
Special Price
£25.72
£21.43
Regular Price
£42.85
Why Choose the 11BG0040A110?
Engineered for reliable switching in modern control circuits, the Lovato 11BG0040A110 is a control relay with AC coil 50/60Hz delivering four normally-open contacts. Designed for 110 VAC coil operation, it fits screw or 35 mm DIN rail mounting to streamline panel integration. With Ui 690 V, Uimp 6 kV and Ith 10 A, it supports robust signalling and interlocking duties across industrial environments.
Built to last, this BG00 series control relay achieves a mechanical life of 20,000,000 cycles and operates from -50 to +70 °C, with storage from -60 to +80 °C and use up to 3,000 m altitude. Conforming to IEC/EN 60947-1 and 60947-5-1, plus UL and CSA equivalents, it delivers dependable performance wherever clean 4NO signalling is required in control panels and automation cabinets.
Key Benefits
- 110 VAC AC coil 50/60Hz for standard control supplies.
- Four normally-open contacts for straightforward signalling and interlocking.
- High insulation and impulse withstand: Ui 690 V, Uimp 6 kV.
- 10 A thermal current (Ith) supports robust control-level switching.
- Operates from -50 to +70 °C for harsh environments.
- Long mechanical life of 20,000,000 cycles reduces maintenance.
- Flexible screw or 35 mm DIN rail mounting.
- Conforms to IEC/EN 60947-1 and 60947-5-1.
Technical Specification
- Product type designation: BG00
- Number of poles: 4
- Rated insulation voltage Ui (IEC/EN): 690 V
- Rated impulse withstand voltage Uimp: 6 kV
- Ith (IEC): 10 A
- Terminal tightening torque: 0.8 to 1 Nm
- Weight: 200 g
- Mechanical life: 20000000 cycles
- Operating temperature: -50 to +70 °C
- Storage temperature: -60 to +80 °C
- Max altitude: 3000 m
- Pollution degree: 3
What’s Included
- Lovato 11BG0040A110 control relay
- Quick installation and safety instructions
- Product datasheet reference
- Manufacturer packaging
Applications
- Industrial control panels and automation cabinets
- Machine interlocking and auxiliary switching
- HVAC and building services control circuits
- Process signalling and status indication
- OEM equipment requiring 4NO relay logic
Frequently Asked Questions
What is the coil voltage and frequency of the 11BG0040A110?
The coil is rated 110 VAC and operates at 50/60 Hz.
How many and what type of contacts does it have?
It provides four normally-open auxiliary contacts (4NO).
How can this relay be mounted in a panel?
It supports screw mounting or 35 mm DIN rail installation.
What environmental limits does it meet?
It operates from -50 to +70 °C and up to 3000 m altitude.
Which standards and approvals does it comply with?
It conforms to IEC/EN 60947-1 and 60947-5-1, plus UL and CSA equivalents.
Safety note: Install and commission only by qualified personnel. Isolate power before work, tighten terminals to 0.8–1 Nm, and operate within rated Ui, Uimp, Ith and temperature limits in accordance with applicable standards.
| Manufacturer Part Number | 11BG0040A110 |
|---|---|
| Manufacturer | Lovato |
| HS Code | 85365080 |
| Barcode | 8013975080382 |
| Alternative Product SKU | BG0040A110 |
| Coil Voltage | 110V |
