11BG0031A400 - CONTROL RELAY BG00.31A 400V 50-60HZ
MPN: 11BG0031A400
Alt. SKU: BG0031A400
Special Price
£25.72
£21.43
Regular Price
£42.85
Why Choose the 11BG0031A400?
Lovato’s 11BG0031A400 control relay brings reliable switching to AC and DC control circuits. Featuring a 400VAC AC coil (50/60Hz), four poles with 3NO+1NC auxiliary contacts, and versatile screw or 35mm DIN rail mounting, it integrates smoothly into control panels. Rated insulation voltage Ui 690V and impulse withstand Uimp 6kV provide robust electrical performance for demanding industrial environments.
Built for endurance and range, this BG00-series relay delivers 20,000,000 mechanical cycles and operates from -50 to +70 °C up to 3000 m altitude. With Ith 10A and terminals tightened to 0.8–1 Nm, it ensures secure connections. Conforming to IEC/EN 60947-1 and 60947-5-1, plus UL and CSA standards, it suits pollution degree 3 applications and weighs 200 g for easy handling.
Key Benefits
- 400VAC 50/60Hz AC coil for dependable operation on 400VAC supplies
- 4-pole 3NO+1NC configuration for flexible auxiliary switching
- High insulation (Ui 690V) and 6kV impulse withstand enhance safety margins
- Long mechanical life of 20,000,000 cycles reduces maintenance
- Wide -50 to +70 °C operating range suits harsh conditions
- Screw or 35mm DIN rail mounting speeds panel installation
- Complies with IEC/EN, UL, and CSA standards for conformity
- Thermal current Ith 10A supports robust control circuit loads
Technical Specification
- Product type designation: BG00
- Number of poles: 4
- Rated insulation voltage Ui (IEC/EN): 690 V
- Rated impulse withstand voltage Uimp: 6 kV
- Ith (IEC): 10 A
- Terminal tightening torque: 0.8 to 1 Nm
- Weight: 200 g
- Mechanical life: 20000000 cycles
- Operating temperature: -50 to +70 °C
- Storage temperature: -60 to +80 °C
- Max altitude: 3000 m
- Pollution degree: 3
What’s Included
- Lovato 11BG0031A400 control relay (BG00 series)
- Product datasheet (PDF download)
- Protective manufacturer packaging
Applications
- Auxiliary switching in industrial control panels
- AC and DC control circuit interfacing and signal relay
- Machine and process automation cabinets
- HVAC and building services control systems
- OEM equipment and panel builder projects
Frequently Asked Questions
What is the coil voltage and frequency?
The coil is 400VAC rated and operates at 50/60Hz.
What is the contact configuration?
It has four poles with built-in 3NO + 1NC auxiliary contacts.
How can this relay be mounted?
It supports screw mounting or 35mm DIN rail installation.
Which standards does it meet?
It conforms to IEC/EN 60947-1 and 60947-5-1, plus UL and CSA equivalents.
Can it be used in DC control circuits?
Yes, it suits AC and DC control circuits; the coil requires 400VAC 50/60Hz.
Safety note: Install and commission by qualified personnel only. Isolate power before wiring, tighten terminals to 0.8–1 Nm, and operate within specified voltages, temperatures, and pollution degree conditions.
| Manufacturer Part Number | 11BG0031A400 |
|---|---|
| Manufacturer | Lovato |
| HS Code | 85365080 |
| Barcode | 8013975081785 |
| Alternative Product SKU | BG0031A400 |
| Coil Voltage | 400V |
