11BG0022A400 - CONTROL RELAY BG00.22A 400V 50-60HZ

Why Choose the Lovato 11BG0022A400 Control Relay?

The Lovato 11BG0022A400 is a compact and reliable 4-pole control relay designed for industrial automation, control panels and auxiliary switching applications. As part of the advanced Lovato BG series, this industrial relay provides dependable switching performance for machine control circuits, signalling systems and automation equipment.

Engineered for industrial environments, the BG series combines compact dimensions with robust electrical performance. The 11BG0022A400 features a 400 V AC 50/60 Hz coil and includes 2 normally open and 2 normally closed contacts, making it ideal for versatile control and interlocking applications in industrial automation systems.

Designed for both screw mounting and DIN rail installation, this relay enables straightforward integration into electrical cabinets and control panels. Its compact footprint and reliable switching characteristics make it suitable for OEM machinery, HVAC systems, power control applications and industrial automation assemblies.

Key Advantages

• Compact industrial control relay for automation applications.
• 400 V AC 50/60 Hz coil for industrial control circuits.
• 2NO + 2NC contact configuration for flexible switching.
• Suitable for DIN rail and screw mounting.
• Reliable industrial switching performance.
• Compact design simplifies panel integration.

Key Features

• Lovato BG series control relay.
• 4-pole relay configuration.
• 400 V AC coil, 50/60 Hz.
• 2 normally open + 2 normally closed contacts.
• Compact DIN rail mounting format.
• Screw terminal connections.
• Industrial control and signalling functionality.
• Designed for automation and auxiliary switching applications.

Technical Specifications

• Manufacturer: Lovato Electric
• Series: BG Series
• Model: 11BG0022A400
• Product type: Control relay
• Number of poles: 4
• Contact configuration: 2NO + 2NC
• Type of coil: AC coil 50/60 Hz
• Rated coil voltage: 400 V AC
• Rated operational current: 10 A AC1
• Rated insulation voltage: 690 V
• Mounting type: Screw / DIN rail 35 mm
• Terminal type: Screw terminals
• Operating temperature: approx. -50 to +70 °C
• Protection rating: IP20
• Mechanical durability: approx. 20 million operations
• Dimensions: approx. 60 × 45 × 60 mm
• Weight: approx. 178 g
• EAN: 8013975081051

Reliable Switching for Industrial Automation

Industrial control relays such as the Lovato 11BG0022A400 are widely used in automation systems to control auxiliary circuits, signalling functions and interlocking operations. The multiple contact configuration allows flexible integration into machine control systems and industrial electrical panels.

The Lovato BG series is designed for reliable long-term operation in demanding industrial environments. Its compact dimensions, DIN rail mounting capability and dependable switching performance make it suitable for OEM machine building, HVAC controls, process automation and industrial power control systems.

Typical Applications

• Industrial automation systems.
• Electrical control panels.
• Machine control and interlocking circuits.
• HVAC and ventilation systems.
• Signalling and auxiliary switching applications.
• OEM machinery and industrial equipment.

Trusted by Automation Engineers Worldwide

Lovato BG series control relays are trusted by industrial automation engineers and panel builders for dependable switching performance and reliable long-term operation in industrial control systems.
