imo mr07-s-22230 mini cont. relay 4p(2no 2nc) 16a ac1 230vac

Why Choose the IMO MR07-S-22230 Miniature Relay Contactor?

The IMO MR07-S-22230 is a compact and highly reliable miniature relay contactor designed for industrial control systems, automation equipment and machinery switching applications where dependable operation and compact dimensions are essential. As part of the trusted IMO MR Series, this industrial relay contactor delivers robust switching performance for auxiliary circuits, control panels and OEM machinery applications.

Featuring a 4-pole contact configuration with 2 normally open and 2 normally closed contacts, a 16 A AC1 current rating and a 230 V AC operating coil, the MR07-S-22230 is engineered for flexible industrial switching duties. Its compact DIN rail mounting format allows efficient installation inside modern electrical control cabinets while maintaining dependable long-term performance.

The IMO MR Series is widely trusted by OEM manufacturers, machine builders and industrial automation engineers seeking compact relay contactors with industrial-grade durability. Designed to EN 60947-4-1 standards, the MR Series provides reliable switching performance and long operational life in demanding industrial environments.

Key Advantages

• Compact miniature relay contactor for industrial automation systems.
• 4-pole 2NO + 2NC contact configuration for flexible control applications.
• 230 V AC operating coil suitable for industrial control circuits.
• 16 A AC1 switching capability for dependable industrial load control.
• Compact relay-sized format saves valuable panel space.
• DIN rail mounting for fast installation and maintenance.
• Industrial-grade durability for demanding environments.

Key Features

• IMO MR Series miniature relay contactor.
• 4-pole contact arrangement.
• 2 normally open and 2 normally closed contacts.
• 230 V AC operating coil.
• 16 A AC1 current rating.
• 7 A AC3 switching capability.
• Compact DIN rail mounted industrial enclosure.
• Designed for industrial automation and machinery control systems.

Technical Specifications

• Manufacturer: IMO Precision Controls
• Series: MR Series
• Model: MR07-S-22230
• Product type: Miniature relay contactor
• Contact configuration: 2 NO + 2 NC
• Number of poles: 4-pole
• Rated switching current: 7 A AC3
• AC1 current rating: 16 A
• Control coil voltage: 220-240 V AC, 50/60 Hz
• Rated insulation voltage: 690 V
• Mounting type: DIN rail mounting
• Terminal type: Screw terminals
• Mechanical life: approx. 10 million operations
• Protection standard: IEC 60947-4-1 compliant
• Weight: approx. 0.18 kg

Reliable Switching for Industrial Control Systems

Miniature relay contactors such as the IMO MR07-S-22230 are designed to provide dependable switching performance within industrial automation systems while minimising panel space requirements. Their compact footprint makes them ideal for machinery control, OEM equipment and industrial relay applications where reliable switching and flexible contact arrangements are essential.

The MR Series combines industrial-grade switching capability with compact dimensions, allowing control panel builders and automation engineers to integrate efficient relay control into modern electrical cabinets and machine systems. Its DIN rail mounting design enables rapid installation and straightforward maintenance.

Typical Applications

• Industrial automation and machinery control systems.
• Electrical control panels and switchboards.
• OEM machinery and automation equipment.
• Industrial relay and auxiliary switching circuits.
• Compact cabinet installations.
• Control and signalling applications.

Trusted by Industrial Automation Engineers Worldwide

IMO MR Series miniature relay contactors are trusted by industrial engineers and machine builders for compact installation, dependable switching performance and reliable operation in demanding automation environments.
