11BG0610D048 - 3P MINICONTACTOR BG06.10D 48DC
MPN: 11BG0610D048
Alt. SKU: BG0610D048
Special Price
£42.72
£35.60
Regular Price
£71.21
Why Choose the 11BG0610D048?
The Lovato 11BG0610D048 is a three‑pole contactor with a 48 V DC coil, ideal for dependable motor and load switching. Rated AC3 6 A/2.2 kW at 400 V and Ith 16 A (AC1), it includes a built‑in 1NO auxiliary contact. Flexible screw or 35 mm DIN rail mounting speeds panel assembly, while the compact BG06 designation fits space‑constrained control panels.
Designed for durability, it offers a 20,000,000‑cycle mechanical life and operates from −50 to +70 °C. With Ui 690 V and 6 kV impulse withstand, plus 3 HP at 480 V (UL/CSA), it suits demanding installations. Rated Pollution Degree 3 and altitude to 3000 m; terminals tighten to 0.8–1 Nm for secure connections.
Key Benefits
- AC3 switching up to 6A/2.2 kW at 400 V for compact motors.
- 48 V DC coil ensures stable control and reduced chatter.
- Integrated 1NO auxiliary contact for signalling and interlocking.
- Dual mounting: screw fix or 35 mm DIN rail.
- Wide operating temperature −50 to +70 °C for harsh environments.
- High mechanical life of 20,000,000 cycles minimises downtime.
- Rated Ui 690 V and Uimp 6 kV enhance electrical robustness.
Technical Specification
- Product type designation: BG06
- Number of poles: 3
- Rated insulation voltage Ui (IEC/EN): 690 V
- Rated impulse withstand voltage Uimp: 6 kV
- Ith (IEC): 16 A
- Terminal tightening torque: 0.8 to 1 Nm
- Weight: 220 g
- Mechanical life: 20000000 cycles
- Operating temperature: -50 to +70 °C
- Storage temperature: -60 to +80 °C
- Max altitude: 3000 m
- Pollution degree: 3
What’s Included
- Lovato 11BG0610D048 BG06 three-pole contactor (48V DC coil)
- Integrated 1NO auxiliary contact
- Installation leaflet
- Manufacturer datasheet (digital download)
Applications
- Motor starters up to 2.2 kW at 400 V (AC3)
- Pumps, fans and conveyor control circuits
- General switching in industrial control panels
- OEM machinery and automation equipment
- HVAC and building services control
Frequently Asked Questions
What is the coil voltage and type?
It has a DC coil rated at 48 V, suitable for low-voltage control circuits.
Does this contactor include auxiliary contacts?
Yes, it includes one built-in 1NO auxiliary contact.
How can it be mounted in a panel?
It supports screw mounting or 35 mm DIN rail installation.
What are its primary current and power ratings?
It is rated AC3 6 A/2.2 kW at 400 V and Ith 16 A (AC1).
Which standards does it conform to?
It complies with IEC/EN 60947-1 and 60947-4-1, plus UL and CSA equivalents.
Safety note: Installation and servicing must be performed by qualified personnel. Isolate power before work, verify 48 V DC coil compatibility, and tighten terminals to 0.8–1 Nm. Observe environmental and standards requirements.
| Manufacturer Part Number | 11BG0610D048 |
|---|---|
| Manufacturer | Lovato |
| HS Code | 85365080 |
| Barcode | 8013975082669 |
| Alternative Product SKU | BG0610D048 |
| Coil Voltage | 48DC |
