KSA2F - LEVER MICRO SWITCH FASTON TERMINAL
MPN: KSA2F
Special Price
£11.28
£9.40
Regular Price
£18.80
Why Choose the KSA2F?
Lovato’s KSA2F plastic micro switch delivers precise actuation for compact control tasks. Part of the K series, it features a top push rod with a metal high rod plunger, 1NO/NC contacts and Faston terminals for quick, reliable connections. The robust polymer thermoplastic housing supports dependable performance across applications where consistent switching and a small footprint are essential.
Designed for longevity, the KSA2F offers 20,000,000 mechanical cycles and a 15 A Ith (IEC) rating, operating reliably from -25 to +70 °C. Built to Pollution Degree 3 environments and weighing just 34 g, it meets IEC/EN 60947-1, IEC/EN 60947-5-1, IEC/EN 61058-1, UL508 and CSA C22.2 n° 14. Ideal for position sensing, interlocks and general-purpose switching.
Key Benefits
- High mechanical life of 20,000,000 cycles reduces maintenance downtime.
- 15 A Ith (IEC) supports robust general-purpose switching loads.
- Top push rod with metal high rod plunger ensures precise actuation.
- 1NO/NC contacts provide flexible wiring for control circuits.
- Faston terminals enable quick, tool-free connection and replacement.
- Durable polymer thermoplastic housing for reliable, long-term service.
- Compliance with IEC, UL, and CSA standards for assured quality.
Technical Specification
- Product type designation: KSA2
- Ith (IEC): 15 A
- Weight: 34 g
- Mechanical life: 20000000 cycles
- Operating temperature: -25 to +70 °C
- Storage temperature: -40 to +70 °C
- Pollution degree: 3
What’s Included
- Lovato KSA2F plastic micro switch (K series)
- Integrated Faston terminals ready for connection
- Product datasheet and compliance information
- Protective packaging for transit
Applications
- Position sensing and limit detection in machinery
- Interlock and safety signalling in control circuits
- General-purpose switching in industrial equipment
- Appliance and OEM panel integration
- HVAC and building services control tasks
Frequently Asked Questions
What contact configuration does the KSA2F provide?
It features 1NO/NC contacts, allowing both normally open and normally closed switching.
Which terminal type is fitted to this micro switch?
It uses Faston terminals for quick, reliable push-on connections.
What is the rated thermal current (Ith)?
The Ith (IEC) is 15 A, suitable for general-purpose switching duties.
How long is the mechanical life?
It is rated for 20,000,000 mechanical cycles under specified conditions.
What operating temperature range does it support?
The switch operates from -25 to +70 °C, with storage from -40 to +70 °C.
Safety note: Installation and servicing should be performed by qualified personnel. Observe the 15 A Ith rating, use appropriate Faston terminations, and operate within the specified temperature and environmental conditions to maintain compliance.
| Manufacturer Part Number | KSA2F |
|---|---|
| Manufacturer | Lovato |
| Barcode | 8013975148341 |
