ABB CR-S024VDC1RG Interface Relay
MPN: 1SVR405501R3020
Alt. SKU: CR-S024VDC1RG
Special Price
£5.58
£4.65
Regular Price
£8.59
Why Choose the CR-S024VDC1RG [1SVR405501R3020]
The CR-S024VDC1RG is a slim pluggable interface relay, with gold-plated output contacts, which is suitable for direct mounting on a printed circuit board or use in conjunction with ABB's sockets. Plugged into a socket, the combination of relay and socket may be seemlessly snap-on mounted onto a DIN Rail. This relay operates with a 24 V DC rated control supply voltage and has a 1 c/o (SPDT) output with contacts rated at 250 V / 6 A.This slim pluggable interface relays may be used for electrical isolation, amplification and signal matching. Its gold-plated contacts ensure contact reliability particularly necessary in applications where small currents and loads are to be switched. The CR-S relays are 6.2 mm wide and therefore allow for the switching of high currents on a small footprint. Moreover, CR-S relays are UL 94-V0 certified, improving safety by providing high levels flame retardation. Screw and spring sockets, jumper bars and markers are available as accessories.
Technical Specification
- Function: Slim pluggable interface relay with gold-plated contacts for reliable switching.
- Rated Control Supply Voltage: 24 V DC.
- Contact Configuration: 1 changeover (SPDT) contact.
- Contact Ratings: 250 V AC, 6 A; 24 V DC, 6 A (DC-12); 24 V DC, 1 A (DC-13).
- Insulation and Impulse Ratings: Overvoltage category III, Pollution degree 2.
- Degree of Protection: IP20.
- Mounting: Direct PCB mounting or snap-on DIN rail with ABB sockets.
- Dimensions: 6.2 mm slim width for space-saving panel design.
- Standards Compliance: CAN/CSA C22.2 No.14, IEC/EN 61810-1, UL 508 certified.
Trusted By Customers Worldwide
"Specified by UK panel builders for dependable control." Controls Engineer, UK
Frequently Asked Questions
What is the rated control supply voltage for the CR-S024VDC1RG relay?
The rated control supply voltage for the CR-S024VDC1RG relay is 24 V DC.
What are the contact ratings for this relay?
The contact ratings are 250 V AC, 6 A; 24 V DC, 6 A (DC-12); and 24 V DC, 1 A (DC-13).
How can the CR-S024VDC1RG relay be mounted?
The relay can be directly mounted on a printed circuit board or snap-on mounted onto a DIN rail using ABB sockets.
What is the width of the CR-S024VDC1RG relay?
The relay is 6.2 mm wide, allowing for a space-saving panel design.
What applications is the CR-S024VDC1RG relay suitable for?
This relay is suitable for electrical isolation, amplification, and signal matching, particularly in applications with small currents and loads.
What certifications does the CR-S024VDC1RG relay have?
The relay is UL 94-V0 certified for flame retardation and complies with CAN/CSA C22.2 No.14, IEC/EN 61810-1, and UL 508 standards.
What is the degree of protection for the CR-S024VDC1RG relay?
The degree of protection is IP20.
| Manufacturer Part Number | 1SVR405501R3020 |
|---|---|
| Manufacturer | ABB |
| Packed Quantity | 1 |
| HS Code | 85364900 |
| Amperage | 6A |
| Number of Poles | 1 Pole |
| Barcode | 4013614499135 |
| Country of Manufacture | China |
| Alternative Product SKU | CR-S024VDC1RG |
| Coil Voltage | 24VDC |
