lovato sm1x16110 sm1 shunt trip releases 110vac 50/560hz
MPN: SM1X16110
Special Price
£31.45
£26.21
Regular Price
£52.43
Why Choose the SM1X16110?
Engineered for dependable remote tripping, the Lovato SM1X16110 shunt trip release accessory pairs seamlessly with SM1P and SM1R devices. Operating at 110VAC 50/60Hz, this SM1X-series accessory helps integrate controlled disconnection into your panel builds. With the SKU SM1X16110 clearly identifying the unit, it offers a straightforward way to add shunt trip functionality to compatible SM1 installations without compromise on specification or quality.
Built to demanding standards, it delivers a rated insulation voltage Ui of 690 V and an impulse withstand Uimp of 4 kV, with a mechanical life of 100000 cycles. Dependable in harsh settings, it operates from -20 to +60 °C and up to 3000 m altitude. Conformity with IEC/EN 60947-1, IEC/EN 60947-5-1, UL508 and CSA C22.2 n° 14 supports compliance needs, while compact construction simplifies panel integration.
Key Benefits
- 110VAC 50/60Hz operation for straightforward control circuit integration.
- Compatible with SM1P and SM1R devices for seamless system matching.
- High insulation and impulse ratings: Ui 690 V, Uimp 4 kV.
- Reliable performance with 100000-cycle mechanical life.
- Wide -20 to +60 °C operating temperature range.
- Conforms to IEC/EN 60947, UL508 and CSA standards.
- Suitable for sites up to 3000 m altitude.
Technical Specification
- Product type designation: SM1X
- Rated insulation voltage Ui (IEC/EN): 690 V
- Rated impulse withstand voltage Uimp: 4 kV
- Terminal tightening torque: 1 to 1 Nm
- Weight: 140 g
- Mechanical life: 100000 cycles
- Operating temperature: -20 to +60 °C
- Storage temperature: -50 to +80 °C
- Max altitude: 3000 m
What’s Included
- SM1X16110 shunt trip release accessory
- Basic installation and safety leaflet
- Product documentation
Applications
- Remote tripping of compatible SM1P and SM1R devices
- Control panels requiring 110VAC shunt trip functionality
- Projects needing compliance with IEC/EN 60947 and UL508 standards
- Installations within -20 to +60 °C operating environments
- Sites up to 3000 m using SM1-series accessories
Frequently Asked Questions
What supply voltage does the SM1X16110 require?
It operates at 110VAC 50/60Hz.
Which devices is this accessory designed for?
It is for SM1P and SM1R devices.
What standards does it conform to?
It conforms to IEC/EN 60947-1, IEC/EN 60947-5-1, UL508 and CSA C22.2 n° 14.
What are its environmental limits?
Operating temperature is -20 to +60 °C, storage -50 to +80 °C, and max altitude 3000 m.
What durability rating does it have?
It has a mechanical life of 100000 cycles.
Safety note: Install and wire only by qualified personnel. Isolate power before work, observe specified voltages, torque and environmental limits, and use only with compatible SM1P and SM1R devices per manufacturer instructions.
| Manufacturer Part Number | SM1X16110 |
|---|---|
| Barcode | 8013975219157 |
| HS Code | 85362010 |
| Manufacturer | Lovato |
