lovato sm1x16024 sm1 shunt trip releases 24vac 50/560hz

Why Choose the SM1X16024?

Designed for dependable remote tripping, the Lovato SM1X16024 shunt trip release accessory delivers precise operation on 24VAC 50/60Hz. Built for SM1P… and SM1R… devices, this compact module integrates cleanly into control panels to enable off‑site or emergency opening. With its SM1X product designation, the SM1X16024 suits installers seeking a robust, manufacturer‑matched solution that helps maintain system safety and compliance.

Engineered to industrial standards, it features Ui 690 V and Uimp 4 kV, with a mechanical life of 100000 cycles. Operating from -20 to +60 °C and suitable up to 3000 m altitude, it weighs 140 g and specifies terminal tightening torque of 1 to 1 Nm. Conformity includes IEC/EN 60947-1, IEC/EN 60947-5-1, UL508 and CSA C22.2 n° 14 for assured compliance.

Key Benefits

• 24VAC 50/60Hz coil provides reliable remote tripping control.
• Compatible with SM1P… and SM1R… device ranges.
• High insulation ratings: Ui 690 V and Uimp 4 kV.
• Wide operating temperature from -20 to +60 °C.
• Long service life with 100000 mechanical cycles.
• Compact 140 g module aids straightforward panel integration.
• Conforms to IEC/EN, UL and CSA standards for compliance.

Technical Specification

• Product type designation: SM1X
• Rated insulation voltage Ui (IEC/EN): 690 V
• Rated impulse withstand voltage Uimp: 4 kV
• Terminal tightening torque: 1 to 1 Nm
• Weight: 140 g
• Mechanical life: 100000 cycles
• Operating temperature: -20 to +60 °C
• Storage temperature: -50 to +80 °C
• Max altitude: 3000 m

What’s Included

• Lovato SM1X16024 shunt trip release module
• Basic installation leaflet

Applications

• Remote tripping of SM1P… and SM1R… installations
• Emergency stop and safety interlock schemes using 24VAC control
• Remote shutdown via control circuits requiring shunt trip actuation
• Industrial and commercial panels installed up to 3000 m altitude

Safety note: Installation and wiring must be performed by qualified personnel. Isolate all power sources before work, observe the 24VAC coil rating and torque requirements, and follow applicable standards.
