lovato sm1x1220 sm1 auxillary contacts side mount 2no

Why Choose the SM1X1220?

Designed for seamless integration with Lovato SM1P and SM1R devices, the SM1X1220 is an add‑on auxiliary contacts accessory that side‑mounts to expand 2NO signalling. With a robust 690 V Ui and 4 kV Uimp, it delivers reliable performance for control and indication needs. This compact module helps extend functionality without redesigning panels, maintaining compatibility within the SM1X family.

Built for endurance, the unit is rated for 100000 mechanical cycles and operates from -20 to +60 °C, with storage down to -50 °C. Terminal connections tighten to 1 Nm for secure wiring, and performance is verified up to 3000 m altitude. Conformity includes IEC/EN 60947-1 and 60947-5-1, plus UL508 and CSA C22.2 n° 14.

Key Benefits

• Side-mount 2NO auxiliary contacts expand SM1P/SM1R functionality.
• Rated insulation voltage 690 V Ui for robust circuit separation.
• 4 kV impulse withstand voltage supports transient resilience.
• Operates from -20 to +60 °C for varied environments.
• 100000 mechanical cycles for dependable longevity.
• Complies with IEC/EN 60947, UL508 and CSA standards.
• Terminal tightening torque up to 1 Nm for secure connections.
• Lightweight 36 g accessory eases panel integration.

Technical Specification

• Product type designation: SM1X
• Rated insulation voltage Ui (IEC/EN): 690 V
• Rated impulse withstand voltage Uimp: 4 kV
• Terminal tightening torque: 1 to 1 Nm
• Weight: 36 g
• Mechanical life: 100000 cycles
• Operating temperature: -20 to +60 °C
• Storage temperature: -50 to +80 °C
• Max altitude: 3000 m

What’s Included

• SM1X1220 side-mount 2NO auxiliary contact block
• Installation leaflet
• Manufacturer packaging

Applications

• Adding two normally open auxiliary contacts to SM1P/SM1R assemblies
• Panel building where side-mounted auxiliary signalling is required
• Industrial control and indication expansion on compliant systems
• Retrofitting additional NO contacts to existing SM1X-compatible setups

Safety note: Install and wire only when de-energised, by qualified personnel. Tighten terminals to the specified 1 Nm and operate within the stated electrical and environmental ratings.
