KXCML03 - METAL BODY C/W CONTACTS 3NC SLOW

Why Choose the KXCML03?

Engineered by Lovato, the KXCML03 Accessories body is a metal-bodied assembly complete with contact block, designed to EN 50047 dimensions. It features a robust aluminium-zinc alloy housing and a single M20 bottom cable entry, with 3NC slow action contacts pre-fitted. Ideal for maintaining consistency across installations and ensuring dependable actuation performance.

Built to recognised control equipment standards, including IEC/EN 60947-1, IEC/EN 60947-5-1, EN 60204-1, UL508 and CSA C22.2 n° 14, this accessory supports seamless integration. As an accessory for KB…, KC…, KM… and KN… devices, it helps standardise builds where EN 50047 dimensions and bottom M20 cable entry are specified, promoting reliable wiring and straightforward replacement.

Key Benefits

• Durable aluminium-zinc alloy housing for reliable mechanical stability.
• Pre-fitted 3NC slow action contacts for consistent operation.
• M20 bottom cable entry simplifies routing and termination.
• Conforms to EN 50047 dimensional standard for straightforward alignment.
• Accessory for KB…, KC…, KM…, KN… ranges, aiding platform consistency.
• Compliant with IEC/EN 60947 and EN 60204-1 requirements.
• Metal body construction supports dependable service life.

Technical Specification

• Type of product: Accessories
• Housing material: Aluminium-zinc alloy
• Type of contacts: 3NC Slow action
• Cable entry: M20 on the bottom
• Type of accessories: Body complete with contact block
• Accessories for: KB…, KC…, KM…, KN…

What’s Included

• Body complete with contact block (KXCML03)
• Integrated M20 bottom cable entry interface
• Metal housing (aluminium-zinc alloy)
• Protective packaging for transit

Applications

• Accessory for Lovato KB…, KC…, KM…, KN… devices
• Installations requiring EN 50047 dimensional compliance
• Projects specifying 3NC slow action contact arrangements
• Panels needing a bottom M20 cable entry orientation

Safety note: Install and wire only by qualified personnel. Isolate power before work, use suitable M20 cable glands, and follow IEC/EN 60947 and EN 60204-1 practices. Verify compatibility with KB…, KC…, KM…, KN… devices.
