imo b10b3016a mcb 10ka, b curve 3pole 16a, 415vac vde

Why Choose the IMO B10B3016A Miniature Circuit Breaker?

The IMO B10B3016A is a dependable 10kA miniature circuit breaker (MCB) designed to protect electrical circuits against overloads and short circuits in industrial, commercial and panel building applications. Manufactured by IMO Precision Controls, this compact protective device provides reliable circuit protection for three phase systems where consistent performance and safe isolation are essential.

Featuring a B curve tripping characteristic, the B10B3016A is suitable for general circuit protection where moderate inrush current is expected. It is commonly used in distribution boards, control panels, lighting circuits, small power circuits and industrial control systems. The DIN rail mounted format supports fast installation and straightforward integration into new or existing electrical assemblies.

With a rated current of 16A, three pole configuration and 240/415V AC operating voltage, the IMO B10B3016A is ideal for protecting three phase circuits in machinery, automation panels and commercial electrical installations. Its 10kA breaking capacity ensures reliable fault protection in demanding environments.

Key Advantages

• High performance 10kA breaking capacity for reliable fault protection.
• B curve tripping characteristic for general purpose circuit protection.
• 16A rated current suitable for power and control circuits.
• Three pole protection for three phase electrical systems.
• Compact TS35 DIN rail mounting for easy panel installation.
• Built to recognised IEC/EN, CE, VDE and KEMA standards.

Key Features

• IMO B10 miniature circuit breaker series.
• 16A rated current.
• 10kA short circuit breaking capacity.
• B curve tripping characteristic.
• Three pole (3P) configuration.
• 240/415V AC operational voltage.
• 60V DC operational voltage.
• Compact DIN rail mounted housing.

Technical Specifications

• Manufacturer: IMO Precision Controls
• Series: B10 Miniature Circuit Breakers
• Model: B10B3016A
• Product type: Miniature circuit breaker (MCB)
• Rated current: 16A
• Number of poles: 3 Pole
• Tripping characteristic: B Curve
• Breaking capacity: 10kA
• Operational voltage: 240/415V AC, 60V DC
• Insulation voltage: 240/415V AC
• Mounting type: TS35 DIN rail
• Terminal capacity: 1 to 25 mm² flexible cable
• Dimensions (H × W × D): approx. 85.5 × 52.7 × 78 mm
• Weight: approx. 0.3 kg
• Standards: IEC/EN60947-2, IEC/EN60898, CE, VDE, KEMA

Reliable Protection for Three Phase Electrical Circuits

Miniature circuit breakers such as the IMO B10B3016A automatically disconnect a circuit when overload or short circuit conditions are detected. This helps protect cables, equipment and connected loads from damage while supporting safer maintenance and operation within electrical installations.

The B curve response makes this MCB well suited to general purpose circuits with lower starting currents than heavy inductive machinery. Its robust construction, compact width and DIN rail compatibility make it a practical choice for panel builders, electrical contractors and maintenance engineers.

Typical Applications

• Three phase distribution boards.
• Industrial control panels.
• Commercial electrical installations.
• Lighting and small power circuits.
• Automation and machinery control systems.
• Panel building and electrical maintenance.

Trusted by Electrical Professionals Worldwide

IMO B10 miniature circuit breakers are widely used by panel builders, contractors and maintenance engineers for dependable circuit protection, compact installation and reliable operation in industrial and commercial electrical systems.
