HR604CD024 - INDUSTRIAL RELAY 4C/O 5A 24VDC + LED
MPN: HR604CD024
Special Price
£5.59
£4.66
Regular Price
£9.31
Why Choose the HR604CD024?
The Lovato Industrial Relay HR604CD024 delivers dependable switching for control circuits. With a 24VDC relay control voltage, 4 C/O contacts and a 5 A IEC conventional free air thermal current, it suits a wide range of panel tasks. An LED state indicator provides clear status at a glance, while the mechanical actuator enables manual operation and testing. Designed for fitting on socket HR6XS4, it simplifies maintenance and replacement.
Engineered for harsh environments, the HR604C platform offers robust electrical performance with 500 V rated insulation and 4 kV impulse withstand. A long mechanical life of 20,000,000 cycles supports reliable service, and an operating temperature from -40 to +70 °C broadens deployment. Conforming to IEC/EN 61810, this industrial relay is a strong choice for UK control panels, machine automation and building services control.
Key Benefits
- 24VDC control voltage compatible with common industrial control circuits.
- Four changeover contacts provide flexible switching for multiple loads.
- Clear LED state indicator aids quick diagnostics and status checks.
- Mechanical actuator allows manual operation and function testing.
- 5 A Ith rating supports dependable low-to-medium current switching.
- 500 V insulation and 4 kV impulse withstand enhance safety margins.
- Wide -40 to +70 °C operating range suits challenging environments.
- Long mechanical life of 20,000,000 cycles reduces maintenance frequency.
Technical Specification
- Product type designation: HR604C
- Rated insulation voltage Ui (IEC/EN): 500 V
- Rated impulse withstand voltage Uimp: 4 kV
- Ith (IEC): 5 A
- Mechanical life: 20000000 cycles
- Operating temperature: -40 to +70 °C
- Storage temperature: -40 to +80 °C
What’s Included
- 1 x Lovato HR604CD024 industrial relay
- Installation and user information leaflet
- Protective packaging
Applications
- Industrial control panels and auxiliary circuits
- Machine and process automation systems
- HVAC and building services control
- Signalling, interlocking and interface circuits
- Power distribution auxiliaries and status indication
Frequently Asked Questions
Is a socket included with the HR604CD024?
No. The relay fits on socket HR6XS4, which is supplied separately.
What is the control voltage for this relay?
The relay control voltage is 24VDC.
What contact configuration and current rating does it have?
It has 4 changeover (4 C/O) contacts with a 5 A Ith rating.
Does it provide LED indication and a mechanical actuator?
Yes. It includes an LED state indicator and a mechanical actuator for manual operation.
What is the operating temperature range?
The relay operates from -40 to +70 °C.
Safety note: Installation should be performed by qualified personnel with power isolated. Observe IEC/EN 61810 compliance, adhere to rated limits, and use a compatible HR6XS4 socket within the specified temperature range.
| Manufacturer Part Number | HR604CD024 |
|---|---|
| Manufacturer | Lovato |
| HS Code | 85365080 |
| Barcode | 8013975233634 |
