HR502CD110 - MINIATURE RELAY 2C/O 8A 110VDC + LED

Why Choose the HR502CD110?

Lovato’s HR502CD110 miniature relay combines clear visual status and practical manual operation for dependable switching in control systems. SKU HR502CD110 offers 2 C/O changeover contacts, an LED state indicator and a mechanical actuator, with 110VDC control voltage and an IEC Ith of 8 A. Designed for fitting on socket HR5XS2, it helps speed installation and fault-finding where robust, flexible changeover functionality is required.

Built for longevity and electrical resilience, the HR502C designation provides 250 V rated insulation (Ui) and 6 kV impulse withstand (Uimp) to support reliable isolation. A mechanical life of 10,000,000 cycles and an operating range from -40 to +70 °C suit demanding environments. Conformance to IEC/EN 61810 and a Sustainability certification underline dependable performance from a compact miniature relay.

Key Benefits

• LED state indicator enables rapid visual status checks during diagnostics.
• Mechanical actuator allows convenient manual operation and testing.
• 2 C/O changeover contacts for flexible control and signalling schemes.
• 110VDC control voltage suits DC-driven control circuits.
• Ith 8 A rating supports robust general-purpose switching.
• High insulation and surge withstand: Ui 250 V, Uimp 6 kV.
• Wide -40 to +70 °C operating temperature range.

Technical Specification

• Product type designation: HR502C
• Rated insulation voltage Ui (IEC/EN): 250 V
• Rated impulse withstand voltage Uimp: 6 kV
• Ith (IEC): 8 A
• Mechanical life: 10000000 cycles
• Operating temperature: -40 to +70 °C
• Storage temperature: -40 to +85 °C

What’s Included

• Lovato HR502CD110 miniature relay unit
• Integrated LED state indicator and mechanical actuator
• Manufacturer datasheet (downloadable)

Applications

• Control circuits requiring 110VDC relay control voltage
• General-purpose changeover switching up to 8 A Ith
• Panels needing clear LED status indication for diagnostics
• Installations using HR5XS2 relay sockets
• Equipment operating across -40 to +70 °C environments

Safety note: Installation should be performed by qualified personnel. Isolate power before work, observe all stated ratings and temperatures, and use the specified HR5XS2 socket per the manufacturer’s datasheet.
