HR302CD012 - MINIATURE RELAY 2C/O 10A, 12VDC

Why Choose the HR302CD012?

The Lovato HR302CD012 is a compact miniature relay designed for reliable control in industrial panels and machinery. With a 12VDC control voltage and 2 C/O (changeover) contacts, it supports versatile switching tasks up to an 8 A Ith. Rated insulation voltage is 250 V with 6 kV impulse withstand, and it fits on socket HR5XS2 for straightforward installation and service.

Built for longevity, the HR302C series delivers 10,000,000 mechanical cycles and dependable performance from -40 to +85 °C operating temperature. Conforming to IEC/EN 61810, it offers assured quality and insulation coordination. The design has no LED state indicator or mechanical actuator, keeping the relay simple and robust for space‑constrained builds where miniature form factor, clear specifications and socket compatibility simplify selection, stocking and maintenance.

Key Benefits

• 12VDC control coil for seamless integration with low-voltage systems.
• Dual 2 C/O contacts provide flexible changeover switching capability.
• 8 A Ith supports robust loads in compact installations.
• High 6 kV impulse withstand enhances transient protection.
• Rated insulation 250 V for reliable isolation and safety margins.
• Wide -40 to +85 °C operating range for harsh environments.
• Long 10,000,000-cycle mechanical life reduces maintenance frequency.

Technical Specification

• Product type designation: HR302C
• Rated insulation voltage Ui (IEC/EN): 250 V
• Rated impulse withstand voltage Uimp: 6 kV
• Ith (IEC): 8 A
• Mechanical life: 10000000 cycles
• Operating temperature: -40 to +85 °C
• Storage temperature: -40 to +85 °C

What’s Included

• Lovato HR302CD012 miniature relay
• Product datasheet (PDF download)
• Manufacturer’s compliance and certification summary

Applications

• Industrial control panels and cabinets
• General automation and signalling circuits
• PLC interface and I/O switching
• HVAC and building services control
• Compact machinery and equipment retrofits

Safety note: Install and operate the relay within its stated voltage, current and temperature limits. Always isolate power before wiring, and ensure qualified personnel handle selection and installation.
